70hp 4wd 8 + дисковый переключатель для трактора поставка с завода небольшая
- Категория: Tractors >>>
- Поставщик: Shandong,Tavol,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 558715.14 $* | 569889.44 $* |
| Jul-16-2025 | 453131.73 $* | 462194.91 $* |
| Jun-16-2025 | 549916.31 $* | 560914.65 $* |
| May-16-2025 | 545517.85 $* | 556427.10 $* |
| Apr-16-2025 | 435534.5 $* | 444245.67 $* |
| Mar-16-2025 | 536718.84 $* | 547452.80 $* |
| Feb-16-2025 | 532319.39 $* | 542965.20 $* |
| Jan-16-2025 | 527920.93 $* | 538478.63 $* |
Характеристики
70hp 4wd 8+8 shift disc for tractor factory supply tractor small price
Product Description
![70hp]()
![]()
![45-70]()
Our Advantages
1. Our wheel tractors rank first in sales in China.
2. 14 years of export experience.
3. 30 years tractor production engineer.
| Model | TL704 | |
| Machine parameters | Type | 4×4 |
| Rated Traction( KN) | 16.2 | |
| PTO Max Power (KW) | 43.8 | |
| Dimensions(mm) | 3560×1650×2350 | |
| Wheelbase(mm) | 1965 | |
| Track(mm) | Front wheel(mm) | 1150 |
| Rear wheel(mm) | 1200-1360 | |
| Ground clearance(mm) | Minimum ground clearance(mm) | 330 |
| Minimum turning cricle radius | Use unilateral braking | 2.85±0.20 |
| Not unilateral braking | 3.15±0.30 | |
| Minimum use quality | 1660 | |
| Gearbox | 8F+8R Shuttle Shift | |
| Steering System | hydraulic steering gear | |
| Drive Train | Clutch | double acting clutch |
| Working equipment | Maximum lifting force at 610mm(KN) | ≥10 |
| Suspension mechanism | Three-piont suspension type 1 | |
| PTO shaft | PTO Spedd(r/min) | 540/760(option: 540/1000) |
| Tire | Front wheel specifications | 6.00-16/6.5-16/7.5-16 |
| Rear wheel specifications | 9.5-24/11.2-24/12.4-24 | |
| Engine | Type | Inline, 4 stroke, Water cooled |
| Cylinder | 4 | |
| Optional | Cabin | AC/Heater |
| Roll bar | ||
| Canopy | ||
| Perfusion volume | Radiater(L) | 10 |
| Fuel tank(L) | 29 | |
| Engine oil pan(L) | 5 | |
| Driveline oil (L) | 20 | |
| Lifter(L) | 9.5 | |
| This parameter table is for reference only, everything is based on actual products | ||
