Product Description
High performance low price OEM high end amplifier kit 2.1 hifi audio amplifier
Introduction
To meet modern home’s demand for high quality and fashionable products. Tonewinner has developed a new generation of HIFI products. AD-86PRO HI-FI is one of these products, which is a new generation of middle grade HiFi amplifier to meet the young audio fanciers’ demand for fashionable appearance, exquisite sound.
Main Features
1.Low Distortion High Speed HIFI Lines .
2.Large-sized toroidal transformer, specially-made large-capacity filter capacitor, with plenty of energy.
3.Super A type output technology, no switching distortion.
4.Power amplifier tube using Japan's latest high-power high-frequency HIFI name tube.
5.High-end fine dynamic dot matrix VFD display, three adjustable brightness; Acrylic lens, microcomputer intelligent operating system.
6.Aluminum panel; aluminum remote control .
7.4 analog inputs, one pure power amplifier input, line output, full frequency bass output.
8.4-way coaxial, 1-channel optical digital decoding.
9.CS3310 for electronic volume; 360-degree pulse volume potentiometer.
10.The signal channel adopts imported famous product coupling capacitor; the filter capacitor of the pre-stage power supply adopts ELAN capacitor.
11.High-grade gold-plated input with the core socket; high-end atmospheric gold-plated output terminal.
2.Large-sized toroidal transformer, specially-made large-capacity filter capacitor, with plenty of energy.
3.Super A type output technology, no switching distortion.
4.Power amplifier tube using Japan's latest high-power high-frequency HIFI name tube.
5.High-end fine dynamic dot matrix VFD display, three adjustable brightness; Acrylic lens, microcomputer intelligent operating system.
6.Aluminum panel; aluminum remote control .
7.4 analog inputs, one pure power amplifier input, line output, full frequency bass output.
8.4-way coaxial, 1-channel optical digital decoding.
9.CS3310 for electronic volume; 360-degree pulse volume potentiometer.
10.The signal channel adopts imported famous product coupling capacitor; the filter capacitor of the pre-stage power supply adopts ELAN capacitor.
11.High-grade gold-plated input with the core socket; high-end atmospheric gold-plated output terminal.
Specifications
Parameters | AD-86PRO/AD-86PRO+ | SNR | ＞100dB |
Frequency | 20Hz-60KHz（+1/-3dB） | THD | ＜0.05%（1KHz，normal work） |
Channel | 2 | Impedance | 8Ω |
Power Consumption | 400W/4Ω | Unit output power | 120W（8Ω，THD=1%,1KHz） |
Size | 444x160x455mm | N.W | 18.5kg |
Audio Decoder Form | analog dual channel | Whole Unit Gain | 41dB |
Applicable Places | living room,club,bar,cafe shop,bedroom,meeting room,etc. | Accessories | telecontrollerX1,wireX1,mini knifeX1,batteryX2. |
Power supply | Support ~220V only |
