MPEG2 HD к RF ATSC QAM J.83B модуляция 1080p модулятор мини
- Категория: Radio & TV Broadcasting Equipment >>>
- Поставщик: Catcast,Technology,Co.,Ltd.,(chengdu)
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 179.42 $* | 188.10 $* |
| Aug-17-2025 | 177.45 $* | 186.45 $* |
| Jul-17-2025 | 149.66 $* | 156.24 $* |
| Jun-17-2025 | 174.2 $* | 183.89 $* |
| May-17-2025 | 152.38 $* | 160.85 $* |
| Apr-17-2025 | 171.49 $* | 180.6 $* |
| Mar-17-2025 | 170.69 $* | 179.29 $* |
| Feb-17-2025 | 168.65 $* | 176.99 $* |
| Jan-17-2025 | 167.2 $* | 175.27 $* |
Характеристики
MPEG2 HD to RF ATSC QAM J.83B Modulation 1080p ATSC Modulator Mini Enocoder Modulator
Product Description
HPR1904E encoder modulator is the most cost-effective and smallest form factor solution in the market. 1 channel HD input, MPEG-2 encoding, ATSC & QAM/J.83B modulation, 1 RF output, user can easily install the system with different requirements. Extremely compact and wall mountable, It fits into any space virtually. It is widely used in Mexico, USA, Canada, Korea
Key Features
1. 1 channels HD input, support HDCP
2. Extremely compact with less than 3CM height
3. Support MPEG-2 encoding, ATSC & QAM/J.83B modulation
4. MER greater than 35dB
5. High output level with 45dBmV MAX
6. Built-in Web UI allow for easy set-up and control visa the web browser
Specification
ENCODING | ||||||||
Input Connector | HDMIx1.4 | |||||||
VIDEO | Encoding | MPEG-2 | ||||||
Input Resolution | 1920*1080_60P; 1920*1080_50P; 1920*1080_60i; 1920*1080_50i; 1280*720_60P; 1280*720_50P | |||||||
Bitrate | 2 ~ 18 Mbps | |||||||
AUDIO | Encoding | MPEG 1 Layer II | ||||||
Sample Rate | 48KHz | |||||||
Bitrate | 384kbps | |||||||
MODULATION | ||||||||
ATSC | Standard | ATSC A/53 (6M) | ||||||
Constellation | 8VSB | |||||||
MER | ≥ 32 dB | |||||||
DVB-C J.83B | Standard | Annex B (6M) | ||||||
Constellation | 64QAM, 256QAM | |||||||
MER | ≥ 36 dB | |||||||
OUTPUT | ||||||||
RF | Output Level | ≥ 45 dBmV | ||||||
Output Frequency Range | 50 ~ 999.999MHz | |||||||
Out-band Rejection | ≥ 60dB | |||||||
SYSTEM | ||||||||
Management | Control Keys; NMS; | LCN Insertion | YES | |||||
Language | English | Upgrade | NMS | |||||
GENERAL | ||||||||
Power Supply | DC 12V | Power Consumption | ||||||
Related Products
Packing&Shipping
Package type: each pcs wth soft ,safety polyfoam ,then packed in brown box
Shipping way: it usually take 5-7 days by DHL, TNT, Fedex, UPS to arrive your local place
Company Introduction
Catcast Technology Co.,Ltd is a high-tech enterprise which concentrates on the research, manufacture, sale and engineer service of digital TV headend & broadcasting equipments with 18 years history in Chengdu, China. Catcast is building up both domestic and overseas markets while making a good contribution to the TV broadcasting industry. As a TV network investor, we have accumulated a great deal of experience in network operation of cable or wireless digital TV, IPTV, DSNG system as well as transfer analog tv system to digital tv system. Upgrade CATV/MATV to IPTV system. We are always striving for innovation , and keep the principle to do business: The same product , we win the quality. The same quality, we win the price.
