As industries have become more aware and responsive to environmental issues, loading systems including top loading arm or bottom loading arm offer a sound solution to the extremely critical process of transferring hazardous products, liquid or gas from bulk-storage tanks to rail tank wagon or road tankers. HONGYI supply top loading arm or bottom loading arm system with features as below: HONGYI's top loading arm and bottom loading arm system composed of pipeline and rotating joint which is flexible rotating, well sealed and durable for severe environment. HONGYI's top loading arm and bottom loading arm system used for loading on open top or sealed top of the tanker or bottom of the tanker; HONGYI's top loading arm and bottom loading arm system can move together with tanker in permissible range during loading and off-loading process. HONGYI's top loading arm and bottom loading arm system can be operated by manual or pneumatic operation; HONGYI's top loading arm and bottom loading arm system's balance can be reached by cylinder spring; HONGYI's top loading arm and bottom loading arm system offer various subsidiary facilities are optional for operation safety or environmental protection; HONGYI's top loading arm and bottom loading arm system's Pipe are made from carbon steel, stainless steel or PTFE carbon steel etc. HONGYI's top loading arm and bottom loading arm system's caliber of Liquid pipeline: 2",3"4" or by customized, Caliber of vapor return line: 1",2",3 etc. HONGYI's top loading arm and bottom loading arm system is designed within temperature range from -196°c to +250°c; HONGYI's top loading arm and bottom loading arm system designed pressure range from PN1.0MPa to PN4.0MPa.
The Fluid Loading arm is divided into the top loading type and the bottom loading type.
Balance Type
Vertical Type
A: Counterweight type
1. 90°c outlet
B: Spring type
2. 45°coutlet
C: Cylinder type
3. Splitter
D: Counterweight cylinder type
4. Flange outlet
E: Counterweight locking bolt type
5. 90°c corner flange outlet
F: Spring cylinder locking bolt type
6. Rigid tube/hose flange outlet
G: Spring cylinder type
7. Sealing cap/90°c outlet
8. Sealing cap/ splitter
9. Sealing cap/ extension tube
Above is typical type of Land loading arm structure. This land loading arm can be customised by either clients' requests or technical parameter or actual site conditions, which can meet various demand from various clients.
Type of loading arm
AL1402Heat Tracing Top Loading Arm
Applicable for road tanker and Tank-Wagon loading gasoline, kerosene, diesel and liquid chemical medium etc at top.
AL1411/1412 SealedTop Loading Arm.
Applicable for road tanker and Tank-Wagon loading medium with volatility and toxicity at top, which is able to recycle volatile gaseous.
AL1401Heat Tracing Top Loading Arm
Applicable for Road tanker and Tank-Wagon loading poor fluidity medium such as crude oil, residual oil, pitch, etc at top. Heat-conducting medium can be either vapor, heat-conduction oil or electric heat tracing.
AL1403Top Loading Arm
Applicable for road tanker and Tank-Wagon loading gasoline, kerosene, diesel and liquid chemical medium etc at top.
AL2543Bottom Loading Arm
Applicable for road tanker and Tank-Wagon loading LPG, Liquid ammonia, dimethyl ether and other chemical products with high volatility at bottom.
AL2503Bottom Loading Arm
Applicable for road tanker and Tank-Wagon loading crude oil, residual oil, CWM and other chemical medium at bottom.
AL1402F1 PTFE-Lined Top Loading Arm
Applicable for road tanker and Tank-Wagon loading acid, alkali and other chamical medium with causticity at top.
AL1512 Top Loading Arm
Applicable for road tanker and Tank-Wagon loading LPG, Liquid ammonia, liquid chlorine and other chemical medium with volatility at top.
Required Parameter from clients for quotation
Optional Components
1.Height of Platform
13.Materials of Pipe
1.Liquid Level Control
2.Distance from Pillar center to platform center
14.Rotation Direction
2.Sealing Cap
3.Distance from Pillar center to tank wagon
15.Stander of entrance flange
3.Operation Platform
4.Minimum Height of entrance of tank wagon
16.Medium Name
4.Detachable Ladder
5.Minimum Diameter of entrance of tank wagon
17.Medium Temperature
6.Maximum Height of entrance of tank wagon
18.Medium Stress
7.Maximum Diameter of entrance of tank wagon
19.Medium Viscosity
8.Length of Sagging pipe
20.Pillar
10.Scop of Docking
21.Base
11.Model
22.Coating Color Code
12.Caliber
Custom loading arms are manufactured with regard to the unique application and custom-design specifications of the customer. In order to design an application-specific custom loading arm, the following are considered:
Liquid product to be handled (temperature and pressure)
Adequate capacity without excessive pressure drop
Physical facility dimensions and limitations
Adequate horizontal and vertical range
Type of tank or container to be used
Factory pre-assembly and testing
Ease of operation/maintenance
Special requirements
Flow rate
Cost
