Китайский производитель прямых продаж поставщика овальной текстильной цифровой трафаретной печатной машины DTG
- Категория: >>>
- Поставщик: Yantai,Youcheng,Printing,Facilities,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 30702.47 $* | 32237.11 $* |
| Aug-17-2025 | 30444.88 $* | 31966.32 $* |
| Jul-17-2025 | 25542.68 $* | 26819.85 $* |
| Jun-17-2025 | 29928.45 $* | 31424.45 $* |
| May-17-2025 | 26058.16 $* | 27361.75 $* |
| Apr-17-2025 | 29412.61 $* | 30883.54 $* |
| Mar-17-2025 | 29154.11 $* | 30612.93 $* |
| Feb-17-2025 | 28896.85 $* | 30341.13 $* |
| Jan-17-2025 | 28638.3 $* | 30070.37 $* |
Характеристики
No | Name | 8 color 36 stations digital machine with oval screen printer |
1 | Model | YC-DPI0836 |
2 | Printing Head Quantity | 8 color |
3 | Table Quantity | 36 pcs |
4 | Regular Pallet Size | 60x80cm |
5 | Max Printing Size | 50x70cm |
6 | Printing Precision | 0.03±mm |
7 | Production Capacity(pcs/h) | 600-1000 pcs/hour(screen)/200-260pcs/hour(digital) |
8 | Total Dryer Power(KW) | 380v12kw*8 |
9 | Dryer Quantity | 8 dryers |
10 | Table Material | Aluminum alloy 6061 |
11 | Total Power(KW) | 380v75kw |
12 | Machine Weight(KG) | 4300kg |
13 | Machine Size(L*W*H) | 1350*450*168cm |
1/ To put our machine in your factory, how much space does it need?
1.Our 10 color screen printing machine is equipped with 36 printing pallets.Its length is 13.5m. Its width
is 3.55m. Its height is 1.68m.
For this machine size, the max pallet size is 60*80cm. If your needing pallet size is bigger, the machine
size will be bigger too.
is 3.55m. Its height is 1.68m.
For this machine size, the max pallet size is 60*80cm. If your needing pallet size is bigger, the machine
size will be bigger too.
2.If you want the 10 color screen printing machine with some other quantity, please just tell us, we will
calculate it and send you our machine design drawings.
calculate it and send you our machine design drawings.
2/ How much electricity does it consume per hour using flash dryers?If not?
The power of one flash dryer machine is 12KW. There are 10 flash dryer machines with a 10 color
automatic screen printing machine. Its total dryer power is 120KW. But in actual use, when all the
dryers are turned on to the maximum power, the power consumption of the machine is about 125
kWh per hour.This kind of operation is almost non-existent.Generally, 60% of the maximum power
will be consumed in actual use.
If you are using a type of ink that does not need to be dried, this machine will consume very little
power. Five kilowatts of electricity per hour will be enough.
automatic screen printing machine. Its total dryer power is 120KW. But in actual use, when all the
dryers are turned on to the maximum power, the power consumption of the machine is about 125
kWh per hour.This kind of operation is almost non-existent.Generally, 60% of the maximum power
will be consumed in actual use.
If you are using a type of ink that does not need to be dried, this machine will consume very little
power. Five kilowatts of electricity per hour will be enough.
3/ How many pieces can it print per hour?
Generally,the printing speed of this machine is 600-1000(pcs/h).But its printing speed in industrial
producing will be related to three main facts:
1.The printing size of your product will be the first factor and it would take more time to
print one piece if your printing size is a big one.
2.The textile ink is the second factor.The variety of ink includes: water slurry,mucilage
(Water-based ink,Oil-based ink), Plastisol, silica gel ink, solvent-based inks.
3.The operating proficiency of printing machine and printing process will can also effect
the speed of printing.
producing will be related to three main facts:
1.The printing size of your product will be the first factor and it would take more time to
print one piece if your printing size is a big one.
2.The textile ink is the second factor.The variety of ink includes: water slurry,mucilage
(Water-based ink,Oil-based ink), Plastisol, silica gel ink, solvent-based inks.
3.The operating proficiency of printing machine and printing process will can also effect
the speed of printing.
4/ What the difference between our machine from others?
1. The configuration of our machine is positioned above mid-to-high end
2. At present, some machines on the market use honeycomb platens, which have short lifespan, are
afraid of high temperatures, are easy to open glue, and are not suitable for long-term drying. The platen
of our machine is made of imported 8mm aluminum alloy super flat plate, which is resistant to high
temperature and does not deform. The surface of the platen has been tempered and polished. The level
accuracy per meter is higher than +-0.05mm and the service life is long.
3. Our machine adopts a quick plate changing device, and the plate changing time is only 3-6 seconds,
which greatly improves the production efficiency.
4. The main structure of the machine adopts high-end aluminum alloy 6061, with a high-end appearance,
and one-piece molding is better than a welded iron body, which greatly maintains the stability of the
machine, and its ultra-low ductility can avoid machine deformation during long-term use.
5. Most of the machines use imported parts, such as motors from Japan, cylinders from Taiwan, bearings
from Germany, etc.
2. At present, some machines on the market use honeycomb platens, which have short lifespan, are
afraid of high temperatures, are easy to open glue, and are not suitable for long-term drying. The platen
of our machine is made of imported 8mm aluminum alloy super flat plate, which is resistant to high
temperature and does not deform. The surface of the platen has been tempered and polished. The level
accuracy per meter is higher than +-0.05mm and the service life is long.
3. Our machine adopts a quick plate changing device, and the plate changing time is only 3-6 seconds,
which greatly improves the production efficiency.
4. The main structure of the machine adopts high-end aluminum alloy 6061, with a high-end appearance,
and one-piece molding is better than a welded iron body, which greatly maintains the stability of the
machine, and its ultra-low ductility can avoid machine deformation during long-term use.
5. Most of the machines use imported parts, such as motors from Japan, cylinders from Taiwan, bearings
from Germany, etc.
SALES AND SERVICE NETWORK
FAQ
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: How does your factory do regarding quality control?
A: We have a special QC department in charge of products’ quality.
3. Q: How’s your ability to do independent research and development?
A: We have our own R&D department, South Korea tech,patent gotten.
4. Q: What is your after-sales service in this year?
A: We provide you with online/video/field installation and training service.But according to the Covid-19 in this year,we will provide you online and video service first,and If you cannot complete the installation work under our guidance, we will find a way to install on site.
5. Q: Do you have an after-sales service team in our country? Or is there an agent?
A: We have agents in some countries. If there is no agent in your country, you are very pleased to be our agent in your country after we sign an agent agreement according to your situation.
6. Q: How long will the machine be delivered?
A: The delivery period of our machines is determined by the size of the machine. Order processing can usually be completed within 20 to 35 days.
A: We are a factory.
2. Q: How does your factory do regarding quality control?
A: We have a special QC department in charge of products’ quality.
3. Q: How’s your ability to do independent research and development?
A: We have our own R&D department, South Korea tech,patent gotten.
4. Q: What is your after-sales service in this year?
A: We provide you with online/video/field installation and training service.But according to the Covid-19 in this year,we will provide you online and video service first,and If you cannot complete the installation work under our guidance, we will find a way to install on site.
5. Q: Do you have an after-sales service team in our country? Or is there an agent?
A: We have agents in some countries. If there is no agent in your country, you are very pleased to be our agent in your country after we sign an agent agreement according to your situation.
6. Q: How long will the machine be delivered?
A: The delivery period of our machines is determined by the size of the machine. Order processing can usually be completed within 20 to 35 days.
