Характеристики
Factory Price 8 Ton Off-road Rough CHINA Terrain Crane
Product Description
Parameters of four-wheel drive off-road crane | |
Engine model | 4102 |
Boom Series | Manganese steel boom, 4m*4 sections |
Outrigger series | 4 full hydraulic outriggers |
Shortener | Dual frequency high and low speed torque converter, air brake |
Rotary series | Slewing support, planetary slewing reducer, swivel universal joint |
Cylinder | Double hydraulic cylinder |
Tires | 16/70-24 |
Dimensions | 8*2.2*3.3m |
Total driving weight | 8ton |
If this model can not meet your work need, please contact me to get more details for the other models
Product Show
Product Details
Product Feature
1. Maneuverable and robust drive
• Four-wheel drive and four-wheel steer chassis;
• Fully hydraulic steering system;
• Variable steering modes, front-wheel steer,four-wheel steer and crab steer;short vehicle length and small turning radius provide the crane with maximum maneuverability and flexibility in narrow job sites
2. Excellent off-road capability
• Big ground clearance and departure / approach angle offer excellent off-road capability.
3. Strong gradeability
• electronically-controlled engine, automated transmission and steerable drive axlex provide reliable power output.
• Even in the condition of abrupt road resistance,the engine can also be functional.
• Four-wheel drive, hydraulic suspension and special tires optimize the vehicle’ s drive performance to its maximum, suitable for any bad roads and job sites.
4. Pick-and-carry operations
• The rough terrain crane has the ability to pick and carry loads, thus improves the working efficiency greatly.
• The crane can also carry out ”On tires“ Lifts without extending the outrigger beams in narrow job sites.
• Superior pick-and-carry ability during short-distance transit can bring great convenience to the users.
5. Single cab design
• Single cab design with large skylight provides large field of view;
• Air-cushioned seat suits to all types of figures, which can release the driver’ s or operator’ s fatigue, thus improves the working efficiency;
• The crane is fitted with air conditioning, suitable for all-weather work;
• Digital display and keyboard units,advanced data bus technology,error check and audible & acoustic alarm ensure the safety and high efficiency of the operation.
Packaging & Shipping
Company Information
Shandong Xinghe Heavy Industry Machinery Co. , Ltd. was established in 2019,The company is located in Jining, Shandong, China,Company to research and development, production, sales, export-oriented,Mainly with a variety of cranes, excavators, concrete machinery, road machinery, pile machinery production research and development, It is widely used in construction, bridge, grid steel structure, landscaping, power installation, offshore lifting and other industries. The quality is stable, the service is prompt, the product use security, the operation comfortableness, the work continuity and so on receives the domestic and foreign user's high praise and the trust.Our products are exported to Thailand, Cambodia, Africa, Canada, Southeast Asia, Pakistan and other countries and regions,The company with professional research system, rich processing experience, perfect The Adjuster, adhering to the "Quality Assurance, quality for survival, credibility for Development" concept, sincerely welcome customers, business associations and friends around the world to negotiate with US cooperation. |  |
FAQ
Q. How many operating methods for my selection?
Standard operating methods:
A: remote control with push buttons
B: cabin(space capsule seat) control with joystick.
Choose any type as you like.
Q. Can this type work in hazardous environment?
A: Sure! We can customize for you, acid proof or explosion proof, no problem for that.
Q. Can you provide the serious lifting tools?
A: Sure, we can provide any lift tools such as lift sling belt, lift clamp, grab, magnet or other specials as your requirement!
Q. Safety device
A: Overload limiter, Limit Switch (lifting and traveling), Interlock protection device.
