China's crop harvester design custom-made, long-term to all countries around the world to recruit agents, the lower the price, the best quality, and strive to give you the best profit Wheat, corn, soybean, olive, peanut and other harvesters
Product Description
Project
Specification
Product number
4LZ-2.5(PRO688Q)
Classification
Big tank
Dimensions
Length (mm)
(transport status / working status)
4950/5010
Width (mm)
(transport status / working status)
2440/2650
Height (mm)
(transport status / working status)
2800/2815
Structure quality (kg) / quality of use (kg)
2790/2905
Matching engine
Model (China second stage)
V2403-M-DI-T-ES04
Structure type
Vertical water cooled 4 - cylinder
turbocharged diesel engine
Total Displacement (L)
2.434
Calibration power (kW)
49.2
Calibration speed (r / min)
2700
Fuel
High quality diesel (0 #)
Fuel tank capacity (L)
60
Walking part
Crawler
Grounding length(mm)
1680
Gauge(mm)
1150
Specifications [pitch
(mm) × section (section)
× width (mm)]
90×51×450
Ground pressure(kPa)
18.1
Minimum ground clearance (mm)
275
Gearbox type
Mechanical speed change + hydraulic
stepless speed change (HST)
Variable speed series
Forward stepless·Back stealth
Vice shift of the three gears
Cutting table
Cutting table width (mm)
2000
Minimum cutting height (mm)
40 (cutter tip)
Lodging adaptability
Cutting: below 85 degrees·
Reverse cutting: below 70 degrees
Threshing part
Threshing method
Sprue axial flow
Threshing drum
Size(mm)(outer
diameter×length)
Φ620×1790
Speed(r/min)
560
Grain processing
department
Capacity (L)
1000
Collecting box
Grain intake (unit)
-
Unloading grain
Dump truck lift
range (degrees)
77 manual operation /80 -
hydraulic operation
Unloading grain unloading
height range (mm)
(working state)
650 ~ 2000 (unloading
grain manual type)
540 ~ 2240 (unloading
cylinder hydraulic type)
Unloading mouth out of the
distance range (mm)
(working state)
950 to 1600 (manual
unloading tube)
990 ~ 1840 (unloading
cylinder hydraulic type)
Adapt to crops
Rice, wheat
Operating hours productivity (hm² / h)
0.2 to 0.4 (upright dry crop)
Packaging & Shipping
Price terms
FOB office
Delivery terms
time: after 15 days
ways: 1.Ship by Express.(DHL.TNT.UPS.FEDEX) 2.Ship by Air express to airport 3.Ship by sea
Payment Item
T/T ,Western Union, L/C, B/L
Port of Shipment
Lianyungang, China
Packing
close package to make shipment safer and suitable for import and export.
NOTE: amend accordng to your demand!
Company Information
construction machinery, engine and all kinds of accessories: 1, all independent and non independent refrigeration unit sales, installation, training and customer service service for 9.6meters van truck. Supplying front, top and chassis types to meet the needs of various types of vehicles;2, Kubota series of machine and accessories' sales and service, including tractors, harvester, rice transplanter, seeding machine etc.;3, Yanmar series of machine and accessories' sales and service, including tractors, harvester, rice transplanter, seeding machine etc.;4, various types of farm implements' sales and service, including rotary machine, strapping machine, mixing machine, grinder, disc plough, glass mower, seeder, harvester etc.;5, all kinds of domestic agricultural machinery and equipment 's customization and sales, can install nameplate as custom's request. Including Harvesters, tractors, transplanter, weeding machine, plant protection machinery etc.;6, Russia MTZ, Romania UTB tractor's full range of accessories sales;7, We are as the overseas agent of Japan's mitsuboshi agricultural belt . including SC52 SC59 SC54 SB58 SB59 toothed belt, reliable quality and reasonable price;8,Can customize all kinds of engine accessories, including the piston, piston rings ,cylinder liner, bearing, crankshaft, cylinder block and cylinder head etc.9.Cummins engine spare parts, include 4b 6b 6c nt855 k19 n14 l10 m11 isf2.8 3.8 etc.
Our Services
A: Your inquiry related to our products or prices will be replied in 24 hours. B: Protection of your sales area, ideas of design and all your private information. C: Best quality and competitive price.
FAQ
Q1. What is your terms of packing? A: Generally, we pack our goods in our W brand box ..
Q2. What is your terms of payment? A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery? A: EXW, FOB, CFR, CIF.
Q4. How about your delivery time? A: Generally, most of items we keep stock for all season . it will take 7to 10 days after receiving your advance payment. .if we didn’t have stock ,The delivery time depends on the items and the quantity of your order. Normaly 30 to 60days .
Q5. What is your sample policy? A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q6. Do you inspect all your goods before delivery? A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
1.Meet small quantity orders and seasonal orders by our sufficient safety stock;
2.Assure best quality with our complete inspection system before shipment
3.Ensure timely delivery to customer’s designated site by our professional management of warehouse and van fleet;
4.Provide in time Feedback tracking and after-sales services to maximize the customer’s satisfactory.
