Портативная буровая установка для бурения скважин KW200 глубина 200 метра
- Категория: Mining Machinery >>>
- Поставщик: Zhengzhou,Kaishan,Mechanical,&,Electrical,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 20468.25 $* | 21491.49 $* |
| Aug-15-2025 | 20296.89 $* | 21311.20 $* |
| Jul-15-2025 | 17028.29 $* | 17879.99 $* |
| Jun-15-2025 | 19952.9 $* | 20950.89 $* |
| May-15-2025 | 17372.80 $* | 18241.51 $* |
| Apr-15-2025 | 19608.11 $* | 20588.66 $* |
| Mar-15-2025 | 19436.55 $* | 20408.26 $* |
| Feb-15-2025 | 19264.28 $* | 20227.22 $* |
| Jan-15-2025 | 19092.92 $* | 20047.31 $* |
Характеристики
Product Overview
KW200 200meter Depth Diesel mobile water well drill rig machine
KW200 series deep(water) well-drilling rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools
with very high drilling efficiency.
Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.Very
flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed
methane, the shallow layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.
The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as
slurry drilling, air drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.
with very high drilling efficiency.
Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.Very
flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed
methane, the shallow layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.
The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as
slurry drilling, air drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.
FEATURES AT A GLANCE
Large Hole Diameter
Deep Drilling
High Penetration Rate, especially under pure rock condition
Flexible Movement
Wide Application Area
Deep Drilling
High Penetration Rate, especially under pure rock condition
Flexible Movement
Wide Application Area
Application:
1. Civil engineering drilling
2. Geothermal drilling
3. Water well drilling
1. Civil engineering drilling
2. Geothermal drilling
3. Water well drilling
Easy Used Control Panel
Strong lifting power
Steel track adaptable to all terrains
PRODUCT SPECIFICATIONS
KW200 trailer mounted water well drilling rig | ||
The weight | 5.8T | |
Drilling diameter | 140-305mm | |
Drilling depth | 200m | |
One-time advance length | 3.4m | |
Walking speed | 2.5km/h | |
Climbing angles | Max.30° | |
Equipped capacitor | 65-70KW | |
Using air pressure | 1.7-3.0Mpa | |
Air consumption | 17-30m³/min | |
Drill pipe diameter | Φ76 mm φ89mm | |
Drill pipe length | 1.5m 2.0m 3.0m | |
Rig lifting force | 12T | |
Swing speed | 45-70rpm | |
Swing torque | 3500-4800N.m | |
Dimension | 4000x1750x2450mm | |
SALES AND SERVICE NETWORK
Successful Project
Project in Thailand
Project in India
Project in Russia
Company Introduction
Zhengzhou Kaishan Mechanical & Electrical Equipment Co., Ltd.is specialized in this filed for over 25 years with high quality and competitive price. The main products we supply are drilling rigs, air compressors and rock drill tools and so on.
главные Рынки North America,Eastern Europe,Central America,Eastern Asia,South America,Africa,Southeast Asia,Mid East основная продукция Machinery,Air compressor,Water well drilling rigs,Drilling rigs,Rock drill
SIMILAR PRODUCTS
Packing&Shipping
Customer Photos
FAQ
Q1: Why customer choose us?
A: Kaishan brand are specialized in water well drilling rig. Germany Standard and 10years exporting experience help us won more
than 50 loyal foreign agents. We warmly welcome your small trial order for quality or market test.
Q2: Are you a manufacturer or trading company?
A: We are professional manufacturer with big modern factory in Zhejiang,China. Both OEM & ODM service can be accepted.
Q3: What's your delivery time?
A: Generally 3 to 7 days, if urgently order, pls contact our sales in advance.
Q4: How long is your water well drilling rig warranty?
A: One year for the whole machine, except consumble spare parts.
Q5: How long could your air compressor be used?
A: Generally, more than 10 years.
Q6: What's payment term?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q7: How about your customer service?
A: 24 hours on-line service available. 48hours problem sovled promise.
Q8: How about your after-sales service?
A: 1. Provide customers with intallation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3. Worldwide agents and after service avaiable
A: Kaishan brand are specialized in water well drilling rig. Germany Standard and 10years exporting experience help us won more
than 50 loyal foreign agents. We warmly welcome your small trial order for quality or market test.
Q2: Are you a manufacturer or trading company?
A: We are professional manufacturer with big modern factory in Zhejiang,China. Both OEM & ODM service can be accepted.
Q3: What's your delivery time?
A: Generally 3 to 7 days, if urgently order, pls contact our sales in advance.
Q4: How long is your water well drilling rig warranty?
A: One year for the whole machine, except consumble spare parts.
Q5: How long could your air compressor be used?
A: Generally, more than 10 years.
Q6: What's payment term?
A: T/T, L/C, D/P, Western Union, Paypal, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q7: How about your customer service?
A: 24 hours on-line service available. 48hours problem sovled promise.
Q8: How about your after-sales service?
A: 1. Provide customers with intallation and commissioning online instructions.
2. Well-trained engineers available to overseas service.
3. Worldwide agents and after service avaiable
