YNP фабрика по производству 3KVA/ 5KVA/ 10KVA/ 15KVA/30KVA 220V/110V ИБП источник бесперебойного питания
- Категория: Uninterrupted Power Supply (UPS) >>>
- Поставщик: Shenzhen,Yuzhou,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 1190.87 $* | 1250.2 $* |
| Aug-19-2025 | 1180.86 $* | 1239.48 $* |
| Jul-19-2025 | 990.65 $* | 1040.34 $* |
| Jun-19-2025 | 1160.40 $* | 1218.20 $* |
| May-19-2025 | 1010.41 $* | 1061.65 $* |
| Apr-19-2025 | 1140.37 $* | 1197.25 $* |
| Mar-19-2025 | 1130.88 $* | 1187.60 $* |
| Feb-19-2025 | 1120.19 $* | 1176.47 $* |
| Jan-19-2025 | 1110.45 $* | 1166.71 $* |
Характеристики
YNP series Factory 3KVA/ 5KVA/ 10KVA/ 15KVA/30KVA 220V/110V UPS Uninterruptible Power cabinet
Product Description
YNP series Factory 3KVA/ 5KVA/ 10KVA/ 15KVA/30KVA 220V/110V UPS Uninterruptible Power cabinet :
1. It is controlled by INTEL special microprocessor
2.Famous IGBT intelligent power module is adopted
3. Pure sine wave output, output steady voltage, steady frequency
4. With over voltage, under voltage, overload, short circuit, input polarity reversed protection functions
5. Invert efficiency ≥90%
6. With ac by pass function
7. Excellent EMI/EMC index of input and output, can be equipped with rs232/485 interface, can realize unattended
8. Line work waveform distortion is small, 0 delay conversion
9. Unique dynamic current loop control technology ensures reliable operation of the inverter
10. Load adaptability, including capacitive, inductive, mixed load
11. Inverter front panel has LCD, LED dual display mode
YNP series Factory 3KVA/ 5KVA/ 10KVA/ 15KVA/30KVA 220V/110V UPS Uninterruptible Power cabinet Application:
- Power Station
- Transformer Substation
YNP series Factory 3KVA/ 5KVA/ 10KVA/ 15KVA/30KVA 220V/110V UPS Uninterruptible Power cabinet Technical Parameters:
| Capacity | 10KVA | 20KVA | 30KVA | 40KVA | 50KVA | 60KVA | 70KVA | 80KVA | 100KVA | 120KVA | |
| Input | Voltage Range | 380/ 415/ 460V AC±20% or 35% | |||||||||
| Unity Power Factor | 0.99 or 0.95 or 0.85 | ||||||||||
| Frequency Range | 50(60) Hz ±5% or 10% | ||||||||||
| Phases | 3PH4W+GND | ||||||||||
| Bypass | Bypass cabinet input 220/ 380V AC/ 415V AC ±20% or 35% | ||||||||||
| Battery | DC Voltage | 110V DC or 220V DC or 400V DC | |||||||||
| Type | Sealed Maintenance Free Lead Acid Battery, Gel Battery, NICD Battery | ||||||||||
| Output | Voltage stability | 220V ±1% | |||||||||
| Frequency Stability | ±0.5% | ||||||||||
| Power Factor | 0.7-1(lag) | ||||||||||
| Crest Factor | 3:1 | ||||||||||
| Waveform distortion | <3% linear load | ||||||||||
| Overload Capacity | 100~125% 10mins, 125~150% 60s | ||||||||||
| Overall efficiency | Not less than 92% | ||||||||||
| Bypass | Bypass output(Auto bypass, manual maintenance bypass) 220V AC ±1%, Install AVR and Isolating transformer | ||||||||||
| Indicator | LCD | Microcomputer LCD display, CPU automatically detects data information: UPS operation state, input and output voltage, frequency, current, load, battery condition, power event recording and analysis operation, etc | |||||||||
| LED | |||||||||||
| Communicaion | RS232, RS485 or Modbus | ||||||||||
| Environment | -5~55℃ Long-time Running, Elevation 1000m The rating is not lowered | ||||||||||
Company Information
Packaging & Shipping
Q:Are you a factory or trading company?
A: Our company is a professional manufacturer and trader that is concerned with the design,development
and production more than 20 years
Q:How can i get the quotation ?
A:Pls help to send the pump flow,head,power,caliber,voltage,frequency and quantity so that we could give you an accurate quotation
Q. What is your delivery time?
A: We have the stock with the sample order,7-15 days for container order. ( Busy season may need more days )
Q:What is your warranty ? What do we do in case of problems?
A:one year quality warranty is provided.In case of our quality problem, we will provide replacement by international
courier.Immediate delivery of replacement parts with available in stock, and if not stocking, the time should be depending on material ordering time which is normally 10-15 days
Q.How can we install the pump?
A:We have professional installation team and could provide one stop installation guide
Q:What is your payment terms?
A:Normally, 30% - 50% of total amount by T/T as deposit and balance before delivery. Irrevocable L/C at sight is also
acceptable.The sample order payment with Paypal,Western union are both ok.
Q: How to place order?
A:Send inquiry→Basic quotation→Confirm details→ PI & Contact→Pay deposit→Production (7-15 days)→Pay balance→Delivery (5-8 days by air, 28-35 days by sea.) →After-sale service.
