3 5 M3 Самостоятельная погрузка бетономешалка соответствует европейским сертификатам и барабан поворотное

3 5 M3 Самостоятельная погрузка бетономешалка соответствует европейским сертификатам и барабан поворотное

Цена:758 136,42 ₽*

Количество:

Specification

Specifications for CMT3500R Self Loading Concrete Mixer for sale

Mixing Drum	Mixing Volume	3500 L
		Geometric Volume	5300 L
		Concrete Output	3500 L/ batch , 4 Batches/ hr
		Inclination Angle	16°
		Max. Slewing Angle	270°
		Rotating Speed	0~21 rpm
		Body /Bottom Thickness	4 mm/6 mm(Q345B)
		Overall Size	Φ1750x 2750
Chute	Max. Slewing Angle	90°
		Tilting Method	Mechanically
		Length	450mm +1000 mm (2 Sections)
	Brand	YUCHAI ( Cummins Optional)
Engine	Model	YCD4J22G
	Rated Power/Speed	116 HP /2400 rpm
	Max.Torque/ Speed	390 N.m/2200 rpm
	Bore x Stroke	105 mm x125 mm
	Displacement	4.33 L
	Type	4-Cylinder,In-line,
		Turbo Charged, Water-cooled
	Emission Standard	Euro II
Hydraulic System	Reducer Model	HJ80-43
		Hydraulic Pump Displacement	50/32 mL/r
		Hydraulic Motor Displacement	160 mL/ r
Water Supply System	Water Tank Volume	2 x 280 L
		Water Supply Mode	Self-contained, Hydraulic
		Water Supply Mode		Driven water pump
Chassis	Structure	Articulated Structure
		Drive Type	4 X 4
		Transmission	2 Forward +2 Reverse Shift
		Transmission		(Low+ High Speed)
		Torque converter	YJ280 ( Split Type)
		Gearbox Mode	Counter Shaft, Power-shift
		Wheelbase	2800 mm
		Tread	1700 mm
		Loading Shovel Capacity	500 L
		Brake Type	Air Brake
		Tyre Size	16/70-20
Vehicle	Drum and Shovel Control	By Joystick
		Driver's Cab	Air-conditioner Inside
		Max. Drive Speed	30 km/h
		Grade Ability	30%
		Mini Turning Radius	5300 mm
		Max. Payload	8,500 kg
		Operating Weight	7,500 kg
		Overall Size	7800 x 2700 x 3300 mm
