4.3inch SK-043FE Samkoon interface SAMKOON HMI Touch Screen Display HMI







PRODUCT FEATURES

1. High strength performance configuration



Based on Linux system, the system is stable, efficient, safe and reliable

Industrial grade high performance cortex A8 processor with a dominant frequency up to 600MHz

High capacity 128MB Flash + 128MB DDR3, support external U disk storage

Support HP printer, micro printer

2. Diversified function modules



Support multi group formula, multi window function

Support data acquisition, data alarm function

Support macro instruction based on C language development

Support Chinese input

Support remote monitoring function, support mqtt docking with third-party platform

Support more than 300 PLC communication protocols

Support 50 languages

Rich functions and diversified controls

3. Complete interface embedding



Support multiple communication modes (232 / 422 / 485)

Support USB Download, Ethernet download, U disk update configuration

4. New password mechanism



Configuration file encryption

Installment payment, HMI protection

Multiple security mechanisms, more secure and reliable

5. Rich color selection



Display 16.77 million true colors

6. Strict quality control



Built in single COM port, integrated RS232 / 422 / 485 communication mode, support USB Download





PRODUCT PARAMETERS

Structural specifications

Dimensions:150x93x39mm

Installation hole size:141x84mm

weight:270g

Shell material:Engineering plastics ABS + PC





Power supply / interface:

Power supply:(DC12~24V)±15%

power waste:3W

Serial interface:COM:RS232/422/485

USB Download port:YES

U port:YES

SD card:NO

Ethernet port:NO

CAN:NO
