cat6 utp stp ftp sftp ethernet copper cable price per meter 4 pair lan 1000ft  outdoor jelly filled cat 6  lan cable  cat 6 network cable



Supporting sevice as the trading company ,but only need pay the price as factory.



PRODUCT INFORMATION:

PRODUCT & SPEC.		23/24/26AWG CAT6 UTP/FTP/SFTP
INDESIDE		2/4P
CONDUCTOR	Configuration	4X2X0.5mm±0.02
	Material	BARE COPPER/CCA/CCAG
	Work datapss	160M
INSULATION	Material	HDPE
	PE OD	Φ0.94±0.05mm
PAIRED PITCH	blue/blue&white	12mm
	Orange /Orange   &white	16mm
	green/green&white	14mm
	Brown/Brown&white	18mm
CORE PAIRED	PAIRED SPACING	80mm
		/
	PACKAGE	305M/BOX
	GRROUND	/
CROSS CENTER	PE	/
SHIELDING	Material	Al foil
BRAIDING	Material	no/Copper/Al braiding
	Coverage	60-90%
SKIN	Material	PVC/ROHS/LSZH
	color	optional
	PVC OD	5.8mm±0.2MM
	PVC Thickness	0.54±0.03mm
	SERFACE	SMOOTH
PERFORMANCE	conductor resistanceΩ/100m.20°C	≤9.1Ω
	Conductor allow load current(A)	0.5A
	voltage rating(V)	≤30V
	operating temperature(°C)	≤75°C
PRINTING	According to your requirments



PACKAGE & DELIVERY:

 1.inner box:305M/1000ft  cable-size: 35*35*22 CM  ;carton: 37*37*46CM (2 boxes in a carton)

 2.wooden drum can be supplied.

 Delivery Detail: after checking the box and printing detail, 7-15 days for delivery



SPECIFICATION:

Conductor diameter	Conductor Material	package(pull box)
0.50mm  4CCA+4CCS		305m/box
0.45mm  4CCA+4CCS		305m/box
0.5mm	4CCA+4CCS	305m/box
0.45mm	8CCA	305m/box
0.57mm	8CCA	305m/box
0.57mm	CCA+CCS	305m/box
0.50mm	CCAU	305m/box
0.56mm	CCAU	305m/box
0.5mm	CCC	305m/box
0.57mm	CCC	305m/box
0.5mm	CU	305m/box
0.57mm	CU	305m/box



APPLICATION:

1.Computer network cabling Project

2.Broadband Network Communication

3.Digital ISDN Network and ATM 155Mbps Network

4.Ethernet Network

5.Audio and data transmission



STANDAERD:

TIA/EIA 568A/568B IEEE802.3U/IEEE 802.5  ISO 11801 EN50173.



CERTIFICATE:

RoHS compliant.

Fluke Testing.

UL certificate.

CE certificates.



FLAME RESISTANCE LEVEL:

CMX. CM, MP, CMG, MPG, CMR, MPR



FACTORY:











CERTIFICATES:







OUR SERVICE:

1. Any inquiries will be replied within 24 hours.

2. Professional manufacturer, 12 years manufacturing experience.

3. OEM/ODM available

    1) Printing your logo on the cable.

    2) Printing your logo on the pull our box, make according to your design.

    3) Any your idea on cable, packing box are available.

4. High quality, reasonable and competitive price, fast lead time.

5. Good after-Sale Service.

    1) All products will have been strictly Quality Checked in house before packing.

    2) All products will be well packed before shipping.

6. Faster delivery:

    Sample order in stock, and 3-7 days for bulk production.

7. Payment:

    We can accept payment methods: L/C, D/A, D/P, T/T, Western Union, MoneyGram and Paypal.

8. Shipping:

    We have strong cooperation with DHL, TNT, UPS, FEDES, EMS, China Air Post.

    You also can choose your own shipping way.
