Недорогая солнечная панель 325 Вт стандартные 72 ячейки 5BB поликристаллический
- Категория: Солнечные батареи для сварочного шлема >>>
- Поставщик: Jiangsu,Morel,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.97 $* | 0.95 $* |
| Aug-18-2025 | 0.75 $* | 0.13 $* |
| Jul-18-2025 | 0.20 $* | 0.96 $* |
| Jun-18-2025 | 0.42 $* | 0.37 $* |
| May-18-2025 | 0.85 $* | 0.8 $* |
| Apr-18-2025 | 0.82 $* | 0.56 $* |
| Mar-18-2025 | 0.5 $* | 0.5 $* |
| Feb-18-2025 | 0.9 $* | 0.97 $* |
| Jan-18-2025 | 0.36 $* | 0.39 $* |
Характеристики
Product Description
Specification
Electrical Characteristics (STC) | ||||||||||
Module Type | SKT310P-24 | SKT315P-24 | SKT320P-24 | SKT325P-24 | SKT330P-24 | SKT335P-24 | SKT340P -24 | |||
Maximum Power -Pmax(W) | 310 | 315 | 320 | 325 | 330 | 335 | 340 | |||
Open Circuit Voltage- Voc(V) | 45.3 | 45.4 | 45.7 | 46.1 | 46.3 | 46.5 | 46.6 | |||
Short-Circuit Current - Isc(A) | 8.86 | 9.15 | 9.24 | 9.34 | 9.45 | 9.55 | 9.64 | |||
Voltage at Pmax - Vmp(V) | 36.9 | 37.2 | 37.5 | 37.6 | 37.7 | 37.9 | 38.1 | |||
Current at Pmax - Imp(A) | 8.40 | 8.47 | 8.53 | 8.64 | 8.75 | 8.86 | 8.92 | |||
Module Efficienty - | 16.0 | 16.2 | 16.5 | 16.7 | 17.0 | 17.3 | 17.5 | |||
STC:Irradiance 1000W/ ㎡,Cell Temperature 25 ℃,Air Mass 1.5
Power Tolerance(W) | (0,+4.99) |
Maximum System Voltage(V) | 1000 |
Maxmium Services Fuse Rating(A) | 20 |
Temperature Characteristics
Pmax Temperature Coefficient | -0.40%/℃ |
Voc Temperature Coefficient | -0.32%/℃ |
Isc Temperature Coefficient | +0.05%/℃ |
Operating Temperature | -40~+85℃ |
Nominal Operating Cell Temperature(NOCT) | 45+/-2℃ |
Mechanicial Specifications
External Dimensions | 1956*992*45mm | 1956*992*40mm |
Weight | 23kg | 22.5kg |
Solar Cells | Poly crystalline 156X156mm(72pcs) | Poly crystalline 156x156mm(72pcs) |
Front Glass | 3.2 mm tempered glass,low iron | 3.2 mm tempered glass, low iron |
Frame | Anodized aluminum alloy | Anodized aluminum alloy |
Junction Box | IP67 | IP67 |
Output Cables | 4.0 m㎡,cable length:1000mm | 4.0 m㎡,cable length:1000mm |
Connector | MC4 Compatible | MC4 Compatible |
Mechanical Load | 5400 Pa | 5400 Pa |
Packing Configuration
1956x992x45mm | 1956x992x40mm | |||||
Container | 20' GP | 40'GP | 20'GP | 40'GP | ||
Pieces per Pallet | 23 | 23 | 26 | 26 | ||
Pallets per Container | 10 | 22 | 10 | 22 | ||
Pieces per Container | 230 | 506 | 260 | 572 | ||
***The above parameters are for your reference only, if you have any special requirements ,please feel free to contact us in time***
Glass
> Antireflective glass
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
> Translucency of normal luminance is increased by 2%
> Module efficiency is increased by 2%
> Self-cleaning function
> Service life is as long as 25 years (30 years optional)
Solar Cell
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
> High Efficiency PV Cells
> Appearance Consistency
> Color sorting ensure consistent appearance on each module
> Anti-PID
Frame
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip design glue injection
> Conventional frame
> Silver or black frames are optional
> Boost bearing capability and prolong service life
> Serrated-clip design tensile strength
> Seal-lip design glue injection
Junction box
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
Packing & Delivery
In well protected carton with pallet
Projects
Company Profile
Jiiangsu Morel Energy Co.,Ltd is specializing in producing and providing the total solar power solution for Domestic and International solar power market .Except for our main products such as solar panels, inverter, array box,combiner box ,battery etc, we can also provide the total solutions which include the whole solar mounting brackets, roof solar mounting accessories, solar carport,1-10KW off-grid solar system etc.for residence ,commercial or public utilities.
Our technical experts and consultants have rich experience in engineering,manufacturing and international building standards, which can ensure Morel to provide the most advanced and reliable products for PV industry.
Each Morel product is strictly monitored and inspected or tested according to ISO9001 standard and our client’s requirements.Hence we enjoy high reputation among our customers in Europe,Australia,Americas,Japan,Thailand etc for the superior quality and exquisite workmanship.
Integrity, efficiency, perfect service is our life.We will continually improve our new product design and quality or service to meet the demands of the global market.
.
Our company is located in Jingjiang City,Jiangsu province with convenient transportation, for only 2 hours by car from Shanghai.
You are most welcome to contact us and send us your enquiries.
Our technical experts and consultants have rich experience in engineering,manufacturing and international building standards, which can ensure Morel to provide the most advanced and reliable products for PV industry.
Each Morel product is strictly monitored and inspected or tested according to ISO9001 standard and our client’s requirements.Hence we enjoy high reputation among our customers in Europe,Australia,Americas,Japan,Thailand etc for the superior quality and exquisite workmanship.
Integrity, efficiency, perfect service is our life.We will continually improve our new product design and quality or service to meet the demands of the global market.
.
Our company is located in Jingjiang City,Jiangsu province with convenient transportation, for only 2 hours by car from Shanghai.
You are most welcome to contact us and send us your enquiries.
FAQ
1. who are we?
We are based in Jiangsu, China, start from 2019,sell to Domestic Market(00.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),North America(00.00%),South America(00.00%),Africa(00.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Solar Cells/ Solar Panels/ Solar Inverter/ Solar Systems
4. why should you buy from us not from other suppliers?
1.25-year service life, 25-year warranty
2.Professional team
3.Fast delivery speed
4:high power efficiency
5;good price
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Jiangsu, China, start from 2019,sell to Domestic Market(00.00%),Eastern Europe(00.00%),Southeast Asia(00.00%),North America(00.00%),South America(00.00%),Africa(00.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Solar Cells/ Solar Panels/ Solar Inverter/ Solar Systems
4. why should you buy from us not from other suppliers?
1.25-year service life, 25-year warranty
2.Professional team
3.Fast delivery speed
4:high power efficiency
5;good price
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
