Высокое качество кресло-коляска лестницы Лифт производители гидравлический

Item

Description

Lifting Height

Load Capacity

Table Size

Total Size

Motor Power

Hydraulic home lift(7LSJW)

2m

300kg

1.3x0.9m

1.3×1.3×3.5m

380/220v,2.2kw  single phase

Safety and Warranty

1.Hydraulic drive system,diameterφ80mm x1pcs hydraulic cylinder.

2. Inching Switch control, 24v/DC control voltage.

3. Lifting speed 4-6m/min.

4. Non-pit installation, directly fixed to concrete floor, working both indoors and outdoors.

5.Lift Characteristics: stainless steel covered,

75 degree range automatic ramp,

customized(90 or 180 degree) in and out.

6. Hydraulic overload protective organization.

7. Pump equipped single control solenoid valves to prevent the platform dropping if power failure.You can open the manual dropped valve to lower the platform to the home position.

8. The lifting and lowering process can be stopped immediately by pressing the emergency button.

9. Warranty time: 1 year, apart from man-made fault.

Spare parts and supply technical supporting all the times.

10. Plywood package, LCL, in a 20’ container.
