Озоновый контроллер с релейным аналогом и

Описание и отзывы

Трекер стоимости

Характеристики





Gas Detected	Ozone
Sensing Element	Electrochemical gas sensor
Sensor lifetime	>2 years, removable
Temperature Sensor	NTC
Humidity Sensor	HS series capacitive sensor
Power Supply	24VAC/VDC (power adaptor selectable)
Power Consumption	2.8W
Response Time	<60s @T90
Signal Update	1s
Warm up Time	<60 seconds
Ozone Measuring Range	0~5000ppb (0-5ppm)( 0~9.81mg/m3) 0~1000ppb
Display Resolution	1ppb (0.001ppm) (0.01mg/ m3)
Accuracy	±0.01ppm + 10% reading
Nonlinear	<1%FS
Repeatability	<0.5%
Zero Drift	<1%
Alarm	Buzzer and Yellow or Red backlight switch
Display	Green-normally, Orange – first stage alarm, Red- second  stage alarm.
Temperature/humidity Measuring Range	5℃~60℃ (41℉~140℉)/0~80%RH
Analog Output	0~10VDC(default) or 4~20mA linear output selectable
Analog Output Resolution	16Bit
Relay dry contact Output	Two dry-contact outputs  Max, switching current 3A (220VAC/30VDC), resistance Load
Modbus Communication Interface	Modbus RTU protocol with 19200bps(default)  15KV antistatic protection
Working Condition/Storage Conditions	5℃~60℃ (41℉~140℉)/ 0~ 80% RH
Net Weight	190g
Dimensions	130mm(H)×85mm(W)×36.5mm(D)
Installation Standard	65mm×65mm or 85mmx85mm or 2”×4” wire box
Interface Connection (Max)	9 terminals
Wiring Standard	Wire section area<1.5mm2
Manufacturing Process	ISO 9001 Certified
Housing and IP class	PC/ABS fireproof plastic material, protection class: IP30
Compliance	EMC Directive 89/336/EEC
