Zoomlion официальный гусеничный экскаватор Xe370Cb 37 тонн
- Категория: Excavators >>>
- Поставщик: Evangel,Industrial,(shanghai),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 5950.93 $* | 6248.37 $* |
| Aug-18-2025 | 5900.11 $* | 6195.80 $* |
| Jul-18-2025 | 4950.85 $* | 5198.9 $* |
| Jun-18-2025 | 5800.34 $* | 6090.66 $* |
| May-18-2025 | 5050.35 $* | 5303.87 $* |
| Apr-18-2025 | 5700.50 $* | 5985.11 $* |
| Mar-18-2025 | 5650.28 $* | 5933.6 $* |
| Feb-18-2025 | 5600.9 $* | 5880.5 $* |
| Jan-18-2025 | 5550.73 $* | 5828.90 $* |
Характеристики
Zoomlion Official Manufacturer Ze360e 36 Tons Hydraulic Crawler Excavator for Mining
Product Description
Features
1.Originally imported engine being powerful and robust.
2. Highest engine power of 198 kW among same tonnage excavators.
3.Full-set of KAWASAKI hydraulic system enjoys high quality and high transmission efficiency. Thanks to the advanced electrical control system, fuel consumption is 5% lower than the industry average, and the efficiency is increased by 7%.
4.Four control modes (P, E, B, L) and instantaneous power booster system better adapt the machine to different applications.
5.Heavy-duty track frame for mine construction
6.Track rollers are in replacement of carrier rollers.
7.Design service life of structural parts reaches 15,000 hours.
8.STD rock bucket.
9.Strengthened large-profile boom and stick
10.Bucket teeth made from high-tensile and wear-resistant steel plate
PARAMETER
| Unit | ZE360E | ||
| Key Parameter | Working mass | kg | 34080 |
| Rated power | kw/rpm | 198/2000 | |
| Standard bucket capacity(SAE) | m3 | 1.6 | |
| System flow (Max. pressure/ Max. flow) | - | 32.4/35.3 Mpa 2×264 L/min | |
| Engine model | - | 6C8.3 | |
| Max. torque | N.m/rpm | 1157/1500 | |
| Traveling speed (low/high) | km/h | 3.1/5.1 | |
| Slewing speed | rpm | 9.6 | |
| Gradeability° | ° | 35° | |
| Max. drawbar pull | kN | 264 | |
| Digging force of bucket (ISO) | kN | 219 | |
| Digging force of stick (ISO) | kN | 171 | |
| Basic Parameter | Slewing radius of tail | mm | 3474 |
| Tail length | mm | 3453 | |
| Counterweight ground clearance | mm | 1161 | |
| Min. ground clearance | mm | 499 | |
| Ground contact length | mm | 4140 | |
| Track length | mm | 5042 | |
| Track gauge | mm | 2590 | |
| Track width | mm | 3190 | |
| Track shoe width | mm | 600 | |
| Height of grouser | mm | 36 | |
| Slewing table width | mm | 2995 | |
| Operating Range | Max. excavating radius | mm | 10262 |
| Max. excavating distance | mm | 10059 | |
| Max. excavating height | mm | 9796 | |
| Max. discharging height | mm | 6705 | |
| Max. excavating depth | mm | 6522 | |
| Max. vertical excavating depth | mm | 5742 | |
| Min. slewing radius of front | mm | 4225 |
