CO2 VOC контроллер с 3

Carbon Dioxide

Sensing element

Non-Dispersive Infrared Detector (NDIR)

CO₂ measuring range

0~2000ppm (default)

0~5000ppm (selected in the advanced setup)

CO₂ Accuracy @22℃(72℉)

±50ppm + 3% of reading or ±75ppm (whichever is greater)

Temperature dependence

0.2% FS per℃

Stability

<2% of FS over life of sensor (15 year typical)

Pressure dependence

0.13% of reading per mm Hg

Calibration

ABC Logic Self Calibration Algorithm

Signal update

Every 2 seconds

Warm-up time

2 hours (first time) / 2 minutes (operation)

General Data

Power supply

24VAC/VDC or 100~230VAC(for relay outputs)

Consumption

2.5W avg., 5.5W max.

Relay output

Up to three relay outputs, max.5A/ resistive load/each for control up to three devices.

Analog output

Up to three 0~10VDC linear outputs or PID control outputs

for CO2 & temperature & RH (or TVOC)

Modbus communication (optional)

RS-485 with Modbus protocol, 19200bps rate, 15KV antistatic protection, independent base address.

Color screen

3-color TFT high definition screen displays measurements and setting /working information.

Operation conditions

0~50℃; 0~95%RH, non condensing

Storage conditions

-10~60℃, 0~80%RH

Net Weight

280g

Dimensions

150mm(L)×90mm(W)×42mm(H)

Installation

wall mounting with 65mm×65mm or 2”×4”wire box

Housing and IP class

PC/ABS fireproof plastic material, protection class: IP30

Standard

CE-Approval
