Asphalt Paver SAP120C-8



FEATURES



 Excellent Paving Performance

• High strength screed-- the strongest, most rigid design in the industry. Uses a frame structure with double-layer anti-twist beams to produce consistently stable work.


• Anti-segregation technology used in all aspects of material handling. Fully proportional, independent conveyor and auger control match device speeds to paving speed - fully and independently adjustable for various material types.


• To provide the ultimate in product support, machine controllers can be remotely monitored and even updated!

Stable & Reliable

• Wiring harnesses built to industry standards to provide solid connections and protection against heat, cold and moisture.


• The machine and its systems are designed to work non-stop, 24 hours a day under full load in a 50-degree celsius environment.



PARAMETERS





Model	SAP45C-8	SAP45TC-8	SAP60C-8	SAP90C-8	SAP100C-8	SAP120C-8
Heating Mode	Electric Heated	Electric Heated	Electric Heated	Electric Heated	Electric Heated	Electric Heated
Max. Paving Thickness	25 cm	25 cm	25 cm	35 cm	35 cm	35 cm
Paving Capacity	320t/h	250t/h	450t/h	900t/h	900t/h	1100t/h
Paving Width	4.5m	4.5m	6m	9.2m	10m	12m
Rated Power of Engine	92kW	92kW	97kW	170kW	170kW	170kW
Rated Speed of Engine	1800rpm	1900rpm	2000rpm	2050rpm	2050rpm	1900rpm
Travel Speed	0~2.2km/h	0~20km/h	0~2.5km/h	0~2.4km/h	0~2.4km/h	0~2.8km/h
Working Speed	1.5~20m/min	1.5~25m/min	1.5~20m/min	1~16m/min	1~16m/min	1~16m/min
Dimension	6583*3210*3710	6618*3047*3767	6320*3246*3750	7250*3667*3880	6790*3667*3880	6650*3667*3857
