Cruking 4 5 м небольшими асфальтоукладчик





FEATURES



 Excellent Paving Performance

• High strength screed-- the strongest, most rigid design in the industry. Uses a frame structure with double-layer anti-twist beams to produce consistently stable work.
• Anti-segregation technology used in all aspects of material handling. Fully proportional, independent conveyor and auger control match device speeds to paving speed - fully and independently adjustable for various material types.
• To provide the ultimate in product support, machine controllers can be remotely monitored and even updated!

Stable & Reliable

• Wiring harnesses built to industry standards to provide solid connections and protection against heat, cold and moisture.
• The machine and its systems are designed to work non-stop, 24 hours a day under full load in a 50-degree celsius environment.



PARAMETERS





Model	SAP45C-8	SAP45TC-8	SAP60C-8	SAP90C-8	SAP100C-8
Heating Mode	Electric Heated	Electric Heated	Electric Heated	Electric Heated	Electric Heated
Max. Paving Thickness	25 cm	25 cm	25 cm	35 cm	35 cm
Paving Capacity	320t/h	250t/h	450t/h	900t/h	900t/h
Paving Width	4.5m	4.5m	6m	9.2m	10m
Rated Power of Engine	92kW	92kW	97kW	170kW	170kW
Rated Speed of Engine	1800rpm	1900rpm	2000rpm	2050rpm	2050rpm
Travel Speed	0~2.2km/h	0~20km/h	0~2.5km/h	0~2.4km/h	0~2.4km/h
Working Speed	1.5~20m/min	1.5~25m/min	1.5~20m/min	1~16m/min	1~16m/min
Dimension	6583*3210*3710mm	6618*3047*3767mm	6320*3246*3750mm	7250*3667*3880mm	6790*3667*3880mm
