Горячая Распродажа! 50 Вт 60 80 100 130 4060 6090 1390 co2 лазерный гравировальный станок для резки дерева пластика акрила кожи
- Категория: Лазерные гравировальные машины >>>
- Поставщик: Zhongcan,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 2031.33 $* | 2072.99 $* |
| Jul-18-2025 | 1647.96 $* | 1680.95 $* |
| Jun-18-2025 | 1999.8 $* | 2039.97 $* |
| May-18-2025 | 1983.0 $* | 2023.55 $* |
| Apr-18-2025 | 1583.32 $* | 1615.71 $* |
| Mar-18-2025 | 1951.82 $* | 1990.35 $* |
| Feb-18-2025 | 1935.71 $* | 1974.4 $* |
| Jan-18-2025 | 1919.58 $* | 1957.98 $* |
Характеристики
Model | ZC-DK-CO2 |
Laser Type | CO2 sealed laser tube,water-cooled 10.6um |
Laser Power | 60W/80W/100W/130W/150W/180 |
Marking Area | 1300*900mm 51inch*35inch |
Engraving speed | 0-60000mm/min / 0-2362in/min |
Cutting Speed | 0-30000mm/min / 0-1181in/min |
Repetition Precision | 0.001mm |
Laser Source | Reci/Yongli |
Total Power | 220V±10% /50HZ 110V±10%//60HZ |
Supported Windows | All Windows |
Supported Format | PLT/AI/DXF/BMP/DST/DWG/LAS |
Min. shaping character | Letter 1.0 x 1.0mm |
Highest Scanning Precision: | 2500DPI |
Machine size | 1850*1310*1140mm 72.8*51.5*44.8inch |
package size | 2000*1470*1330mm 78.7*57.8*44.8inch |
Net Weight /Gross weight | 380KGS/500KGS |
Optional part | Up and down table, rotary attachment, red light pointer, auto focus system |
Product Description
01
CO2 Laser Tube
CO2 Laser Tube
Adopt the new high-efficiency CO2 laser tube of RECI, the 100W CO2 laser tube can reach a peak of 122W. The laser beam is more stable and the life of the laser tube can exceed 10,000 hours.
02
Adjustable Laser Head
The aluminum alloy adjustable laser head is lighter than other metal laser heads, which can minimize the inertia error when the laser head moves." The structure is simple, the operation is convenient, the laser device is stable,and the maintenance cost is low.
03
Taiwan HIWIN Guide Slider
Taiwan Hiwin square guide rails are made of high-strength special steel to ensure that the laser machine does not deform continuously for a long time. Improve laser engraving and cutting accuracy and extend the working life of the machine.
04
Perfectly Tidy Power Supply SystemThe power supply system of the whole machine is strictly in accordance with international standards. Different control power signal lines adopt separate routing design, and the whole is clean and tidy, avoiding electromagnetic interference between various types of signal lines.
04
Control Panel
Easy To Operate, Intuitive Control Panel.
05
Universal wheel
The design of the bottom universal wheel is more convenient to move
06
accessory
Laser tube\t\t\t\t
Power cord\t\t\t\t
Data line \t\t\t\t
Focal length ruler\t\t\t\t
Tobacco tube\t\t\t\t
Encryption lock\t\t\t\t
Chimney\t\t\t\t\t\t\t
Focal length ruler \t\t\t\t\t\t\t\t
Toolbox/CD (software/tutorial/instruction)
Power cord\t\t\t\t
Data line \t\t\t\t
Focal length ruler\t\t\t\t
Tobacco tube\t\t\t\t
Encryption lock\t\t\t\t
Chimney\t\t\t\t\t\t\t
Focal length ruler \t\t\t\t\t\t\t\t
Toolbox/CD (software/tutorial/instruction)
07
rotary axis
Suitable for all kinds of cylinders
ABOUT ZHONGCAN
Zhongcan technology CO.,LTD. main product involving Fiber Laser Marking machine , Fiber Laser cutting machine, CO2 Laser Marking machine, CO2 Laser Welding Machine, Laser Engraving machine, Laser Welding Machine, Laser Cleaning machine , Pneumatic Marking Machine etc.we are committed to providing customers with high-quality machine. As a result of our strict quality control system, our laser cutting machine, laser marking machine, all have got CE certification.
Exported Countries: Quality product performance and good reputation, our products are not only successful sales in China, and have been exported to more than 120 countries and regions in the world, including: Germany, Japan, Italy, Russia, Japan, South Korea, Turkey, Brazil , India, the United Arab Emirates,and so on.
As a result of our strict quality control system, our laser cutting machine, laser marking machine, all have got CE
certification.High precision, low energy consumption, Automatic processing, little environmental pollution and make our products more and moreindustries played an important role.
certification.High precision, low energy consumption, Automatic processing, little environmental pollution and make our products more and moreindustries played an important role.
FAQ
Q1: I know nothing about this machine, what type of machine should I choose?
We will help you choose the suitable machine and share you the solution; you can share us what material will you marking /engraving and the depth of marking / engraving.
Q2: When I got this machine, but I don’t know how to use it. What should I do?
We will send operation video and manual for the machine. Our engineer will do training online. If needed, you can send the
operator to our factory for training.
Q3: If some problems happen to this machine, what should I do?
We provide two years machine warranty. During the two-year warranty, in case any problem for the machine, we will provide the parts free of charge (except for artificial damage). After the warranty, we still provide whole lifetime service. So any doubts, just let us know, we will give you solutions.
Q4: What’s consumables of laser engraving machine?
A: It doesn't have consumable. It’s very economical and cost effective.
Q5: How’s the effect of the laser engraving?
If you want to know the effect, you can send the sample or drawing to us, we will do the free sample for you and show you in video how to operate it.
Q6: What’s delivery time?
A: Commonly, the lead time is within 7 working days after receiving the payment.
Q7: How is the shipping method?
A: As per your actual address, we can effect shipment by sea, by truck or railway. Also we can send the machine to your office asper your requirement .
We will help you choose the suitable machine and share you the solution; you can share us what material will you marking /engraving and the depth of marking / engraving.
Q2: When I got this machine, but I don’t know how to use it. What should I do?
We will send operation video and manual for the machine. Our engineer will do training online. If needed, you can send the
operator to our factory for training.
Q3: If some problems happen to this machine, what should I do?
We provide two years machine warranty. During the two-year warranty, in case any problem for the machine, we will provide the parts free of charge (except for artificial damage). After the warranty, we still provide whole lifetime service. So any doubts, just let us know, we will give you solutions.
Q4: What’s consumables of laser engraving machine?
A: It doesn't have consumable. It’s very economical and cost effective.
Q5: How’s the effect of the laser engraving?
If you want to know the effect, you can send the sample or drawing to us, we will do the free sample for you and show you in video how to operate it.
Q6: What’s delivery time?
A: Commonly, the lead time is within 7 working days after receiving the payment.
Q7: How is the shipping method?
A: As per your actual address, we can effect shipment by sea, by truck or railway. Also we can send the machine to your office asper your requirement .
