Priming Diaphragm Mini Pump Spray Motor 12V Micro Pumps For Water Dispenser Max Suction
- Категория: Solar Water Pump >>>
- Поставщик: Ningbo,Yinzhou,Ruituo,Motor,Parts,Factory
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 14.94 $* | 15.46 $* |
| Aug-20-2025 | 14.79 $* | 15.23 $* |
| Jul-20-2025 | 12.40 $* | 13.74 $* |
| Jun-20-2025 | 14.97 $* | 15.86 $* |
| May-20-2025 | 12.38 $* | 13.48 $* |
| Apr-20-2025 | 14.22 $* | 15.21 $* |
| Mar-20-2025 | 14.38 $* | 15.57 $* |
| Feb-20-2025 | 13.64 $* | 14.54 $* |
| Jan-20-2025 | 13.51 $* | 14.94 $* |
Характеристики
Product Description
Using material PP+EPDM after special treatment make the pump quite resistable to extreme chemical fluid such as refridgerating fluid,oxidant ,MEK etc.
Basic characteristic:
1.Oil free lubrication
2.Corrosion resistance
3.Long life;low cost
4.Low noise&power consumption
5.Convenient installation & easy maintenance
specification:
Voltage 12V
Power:7W
Current rating: < 500mA
Vacuum flow:50KPA
Air Flow: 3.2 L
Pressure: 1bar
Liquid flow :320ML
Pressure : 3bar
Noise: <55 dB
Weight: 350g
Flow rate(ml/min) | positive pressure | negative pressure | |
Single head | ≥500 |
0.6bar |
0.5bar |
≥400 | |||
Double head | ≥1000 | ||
≥800 |
Air Parameter
| Model | Air Flow | Negative Pressure | Positive Pressure | Motor | Voltage |
| single head | 3L/min | -0.05MPa | 0.1Mpa | DC,BLDC | 12v,24v |
(double head) | 4.2L/min | -0.05MPa | 0.1MPa | DC,BLDC | 12v,24v |
Liquid Parameter
| Model | Liquid Flow | Suction Height | Pressure Height | Motor | Voltage |
| single head | 320ml/min | 3 meters | 10 meters | DC,BLDC | 12v,24v |
| double head | 600mlmin | 3 meters | 10 meters | DC,BLDC | 12v,24v |
Packaging & Shipping
15 Centimeters * 15 Centimeters * 15 Centimeters
0.400 Kilogram
FAQ
Q:What's your payment terms?
A: Usually we accept T/T ,Western Union or PayPal.
Q: What's your delivery time?
1.The stock samples can be sent to you within 1-5 days by courier after payment.
2.The mass order can be shipped to you within 10-25 days after deposit.
Q:How can I choose the most suitable pump?
A: Please tell me your detailed flow rate, voltage, application, then we can make suggestion for you.
Q: How long is your pump lifetime?
A: Pump lifetime mainly depends on motor lifetime, we have AC motor, DC brush, brushless motor.
