high quality automatic waste tire rasper machine for rubber mulch recycling line



Description

This machine is a special machine for cutting and separating the steel mouth, sidewall and crown of waster tires. First,  put the tire on the platform, then rotate the hand wheel, Then start power supply, work platform rotation, cutting tool according to need to feed, slow cut tires, step by step, until the tire side cut off. It is an ideal environmental protection renewable resource equipment.



Name	Ring cutter
Capacity	25-30 PCS/H
Rotating speed	72r/min
Weight	500 KG
Dimension	1.4*0.9*1.2m







Description

Applications: It is used in cutting the used tire and side wall of waste tire into rubber strip.After using the single ring cutter machine,the tire is cut into circles, then the tire strip cutter machine cut the circles into strips and the width of the strip can be adjusted.It is an ideal environmentally-friendly renewable resource machine.



Name	Tire strip cutter
Capacity	25-30 PCS/H
Discharge size	35-55mm
Rotating speed	28r/min
Weight	800 KG
Dimension	1.35*0.8*1.42m







 Description

This equipment is suitable for the processing of rubber strips into rubber blocks of a certain size.

Features

1. convenient to feed, high output and won’t damage roller easily,

2. which can improve the working efficiency and lower equipment maintenance cost.

3. Environmental-protection, no pollution

Name	Tire lump cutter
Capacity	25-30 PCS/H
Discharge size	35*35*35mm
Rotating speed	480r/min
Weight	600 KG
Dimension	1.05*0.8*1.15m







(1) Application: This machine is mainly used to separate the rubber on the various tires from the steel wire.



(2) Process: The waste tire separator produced by our company is a special device used in conjunction with the wire tire cutting machine for extracting the thin steel wire on the surface of the tire ring cut by the wire tire cutting machine.



Name	Tire steel wire separator
Capacity	120tires/hour
Rotating speed	1440r/min
Motor power	15kw
Dimensions(L*W*H)	1500*900*1400mm
Weight	1300kg







 Description

The rubber granule machine is a product that processes waste rubber products, scraps, used tires, and the like into rubber granules.

Application: Mainly used in sports tracks, highways, high-speed railways, etc., which need to be shock-absorbing, noise-reducing and non-slip.



Model	800	1000
Capacity	300-500kg	300-500kg
Feed size	30-50mm	8-12 mm
Discharge size	10-20mm	1--5mm
Rotating speed	650 r/min	680 r/min
Weight	1000 KG	1200 KG
Dimension	1.65*1.2*2.05m	1.65*1.4*2.05m



Description

Roller type tire rubber grinding equipment is mainly used for the crushing of rubber products such as rubber and tires. The front roller is a polished circular groove surface, the rear roller is a polished serrated groove surface, The inside of the roller is hollow. According to the use requirements, the cooling water circulation can be used to adjust the surface temperature of the roller.The two rolls are rotated relative to each other at different speeds to grind the rubber.



Name	Tire power mill
Capacity	400-500kg
Feed size	30-50mm
Discharge size	5-40
Power	37kw
Weight	2T
