Semi automatic bottle air cleaning machine can be used to clean the interior of various plastic bottles, glass bottles and hoses in the cosmetics and pharmaceutical industries. The trial range is wide, without changing the mold. The machine uses clean compressed air to clean the plastic bottle. The cleaned air is sucked away from the other port. The fully sealed device can effectively suck powder, dust and water droplets in the bottle to achieve the purpose of cleaning plastic bottles and glass bottles.
Working principle
Connect the clean air pipeline of the air compressor, turn on the air supply slide switch to adjust the air pressure to 4-6kg/cm2; turn on the power switch, the vacuum generator starts to run; press the bottle to be cleaned against the working arm and press it down slightly At this time, the cleaning nozzle will open the clean air solenoid valve to automatically spray clean air and inhale into the bottle, wait until the set time to blow and stop working, manually pick up the cleaned bottle; cycle this operation.
Features
1. Low energy consumption, clean and pollution-free; easy to operate, low failure rate; low price.
2. The whole machine is made of 304 stainless steel.
3. Adopt precision double filtration, electrostatic ion generation to ensure no residue of dust particles in the bottle.
4. Automatic storage of dust particles to ensure clean room air and health of the operator.
5. The length of cleaning time can be set according to needs.
6. Use double (blow/inhale) mouthwash to remove dust in the bottle.
7. Use precision filter (0.2um) to ensure clean air source.
8. It is suitable for assembly line operation and can be matched with various assembly lines with high efficiency. It is faster than traditional washing and baking, saving environmental protection.
9. This machine can be used in the production of beverage factories, food factories, chemical factories, cosmetics factories, pharmaceutical factories and other enterprises. Applicable container: PE and glass container, the capacity is less than 500ml.
10. The caster design makes it easy to move.
Technical Parameter
Power supply
AC220V/50HZ
Power
Above 500W according to user requirements
Washing speed
20-40 bottles/min (user setting)
Bottle mouth diameter requirements
Outer diameter 15-65mm, inner diameter minimum 8mm (customized according to bottle mouth)
1. The normal package is wooden box(Size: L*W*H). If export to european countries, the wooden box will be fumigated. If container is too tigher, we will use PE film for packing or pack it according to customers special request.
2. Delivery time: 7-12 days after receiving the deposit. 3. For machines are big and heavy parcel, and different country with different delivery cost, so we suggest below delivery
(1) Over 1CBM or 100KG, recommended shipment by Sea.
(2) Below 1CBM or 100KG, recommended shipment by Air.
(3) Below 0.5CBM or 50KG, recommended shipment by Express.
After Sales Service
1. Manuels / Videos of machine installation, adjusting, setting, maintenance are available for you.
2. If any problems happen and you can not find out the solutions, Telecom or Online face to face communication available 24 hours.
3. Our engineers & technicians are available send to your countries for services if you agree pay the expenditure.
4. The machine will have one year guaranty for machine, two years guaranty for electrical part. During the warranty year if any of the parts broken not by man-made, free charge to replace the new one to you. The warranty will begin after the machine send out we received the B/L.
5. Independent team for after-sale service 24/7 technical support. Any emergency please call the salesman or our after-sales manager.
