Портативное Походное зарядное устройство для аккумуляторов складные солнечные панели гибкая монокристаллическая солнечная
- Категория: Солнечные панели >>>
- Поставщик: Shenzhen,Glory,Industries,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 75.45 $* | 77.46 $* |
| Jul-20-2025 | 61.65 $* | 62.96 $* |
| Jun-20-2025 | 74.3 $* | 75.57 $* |
| May-20-2025 | 73.89 $* | 74.26 $* |
| Apr-20-2025 | 58.47 $* | 59.50 $* |
| Mar-20-2025 | 72.22 $* | 73.23 $* |
| Feb-20-2025 | 71.78 $* | 72.71 $* |
| Jan-20-2025 | 71.19 $* | 72.64 $* |
Характеристики
Outdoor hiking battery charger Portable blanket Foldable panels solar cells folding flexible fotoltaicl panel mono crystalline
Product Description
Specifications – Monocrystalline series – 20W/fold | ||||||
Item No. | GSM-60W | GSM-100WA | GSM-120W | GSM-200W | ||
Max power | 60W | 100W | 120W | 200W | ||
Power tolerance | ±3% | ±3% | ±3% | ±3% | ||
Cells brand | Monocrystalline | Monocrystalline | Monocrystalline | Monocrystalline | ||
Cells efficiency(%) | 19% | 19% | 19% | 19% | ||
Max voltage | 18V | 18V | 18V | 18V | ||
Max current | 3.34A | 5.56A | 6.67A | 11.12A | ||
Open circuit voltage(Voc) | 21.6V | 21.6V | 21.6V | 21.6V | ||
Short-circuit current(Isc) | 3.87A | 6.45A | 7.75A | 12.88A | ||
Unfolded size | 1320*370*5mm | 1835*400*5mm | 2200*400*5mm | 1835*820*5mm | ||
Folded size | 420*370*15mm | 368*400*30mm | 368*400*35mm | 368*410*55mm | ||
Weight | 2.8kgs | 3.75kgs | 4.5kgs | 7.5kgs | ||
Operating Temperature(℃): | -40℃~+85℃ | |||||
Power temperature coefficient | -0.39 to -0.29 %/℃ | |||||
Voltage temperature coefficient | -0.29%/℃ | |||||
Current temperature coefficient | +0.05%/℃ | |||||
Nominal Operating Cell Temperature | 45 ± 2℃ | |||||
Measured at STC Condition: irradiance: 1000W /m2-AM1.5 Spectrum-Temperature: 25℃ | ||||||
