Introduction of  Raymond grinding mill, raymond mill in india

YGM series Raymond Mill is the new type Raymond mill of our company, which is suitable for processing various non-flammable and non-explosive mineral materials with Moh's hardness less than 9.3 and humidity less than 6%. It is widely used in the fields of metallurgy, construction, chemical industry, mining, highway construction etc,. The granularity of the finished powder size can be adjusted between 30 and 425 mesh. Examples of processing materials include quartz, feldspar, barite, calcite carbonate, limestone, talc, ceramic, iron ore, carborundum, bauxite, rock phosphate, coal and other materials, about 400 kinds of materials in total.



Technology Data of Raymond grinding mill, raymond mill in india

Model	YGM7815	YGM8314	YGM9517	YGM4121	MTM1600
Roller Number	3	3	4	5	6
Roller Dimension (mm)	260	270	310	410	440
Roller Height (mm)	140	150	170	210	270
Input Size (mm)	15	20	25	30	35
Fineness (mm)	0.613-0.033
Output (t/h)	1-3	1.2-4.6	2.1-5.6	2.8-10.5	5-20
Powder (kw)	18.5	22	37	75	132
Size (mm)	4300*3500*5100	5300*4100*5200	7100*5900*7900	9200*7250*9700	12550*5700*8350



Working Principle of Raymond grinding mill, raymond mill in india



Raymond mill is mainly composed of main unit, analyzer, fan, discharge cyclone separator, powder cyclone separator and air duct. Among them, the main unit consists of frame, blow shell, shovel, grinding roller and grinding ring. The lump material will be conveyed into the storage bin by the bucket elevator after it is crushed into the required particle size by the jaw crusher. Then electronic vibrating feeder will uniformly transfer the material into the grinding chamber of the host machine. The material is up thrown and fed into the space between the grinding roller and grinding ring in the process of synchronous rotation of the shovel and the grinding roller, and forms a cushion material layer. The material on this layer is grind between the grinding roller and the grinding ring. Thus, the purpose of powder production is achieved. The grind powder will be carried by the airflow of the fan into the analyzer for classification. The powder with the qualified fineness will enter the large cyclone collector, together with the airflow through the pipes, for classification, and then, will be discharged by the discharging device, as the finished product.

Advantages of Raymond grinding mill, raymond mill in india

♦Compared with the ball mill, the Raymond mill has higher efficiency, lower power consumption, smaller covered area, less investment.
♦The grinding roller compressed on the grinding ring tightly due to the centrifugal force.
♦The output and fineness of the finished product will not be affected when the grinding ring is worn to a certain degree.
♦The grinding roller and the grinding ring have a long replacement period, so it gets rid of the shortcoming that the wear parts of centrifugal mills have a short replacement period.
♦The classifying airflow of the Raymond mill flows according to the recycling process as: the fan mill shell cyclone separator the fan.
♦Compared with the high speed centrifugal grinder, there is less powder dust, and the operation room is clean without any pollution.

Our Company

Our company, Shanghai Clirik Machinery Co.,Ltd.,  is a manufacturer of mineral grinding mills.

Micro powder grinding mill is one of our representative products.

And our main products also include: Raymond mill, ultra fine vertical mill, powder surface coating machine, crushers and ore beneficiation plant.

Our address: No.1, Fuqing Road, Heqing Town, Pudong New District, Shanghai, China.

Welcome to visit our company and factory.
