Pengpu Shantui SD22W 220 HP бульдозер цена гусеничный башмак


Поделиться:


Цена:85 000,00 $ - 112 000,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-17-2025 101150.97 $* 106208.10 $*
Aug-17-2025 100300.69 $* 105315.43 $*
Jul-17-2025 84150.33 $* 88358.79 $*
Jun-17-2025 98600.14 $* 103530.70 $*
May-17-2025 85850.35 $* 90143.51 $*
Apr-17-2025 96900.69 $* 101745.3 $*
Mar-17-2025 96050.11 $* 100853.62 $*
Feb-17-2025 95200.53 $* 99960.19 $*
Jan-17-2025 94350.6 $* 99068.48 $*

Характеристики



Buying Guides































Pengpu Shantui SD22W 220 HP Bulldozer Price Track Shoe Swamp Dozer


     Adopt new environmental protection engine, low speed torque, low fuel consumption, high operating efficiency, reliable and durable. The layout of intake pipe is optimized to reduce intake resistance, increase intake and improve fuel efficiency.





   Large space cab spacious and comfortable, more open view, new cab surrounded by shading shade; Optimize the three-stage shock absorption system to further improve seat comfort. Push and pull the Windows on both sides of the cab, greatly improve the operating comfort.





    Advanced built-in boom head, strong structural members and lower sliders with larger area contribute to better stress-bearing capacity and more smooth telescoping movement, and efficiently prevent boom torsion after side loading.



    Telescoping mechanism is designed reliably. In the telescoping mechanism, both rotation-resistant rope used for thick cable and guide pulley bearing are imported parts and have reliable performance.








1.longer time warranty: one year,


2.package:sea protecting package with film not nude wether by container or not.


3.quality is strong with good steel body frame, brand component, technology is mature.


4.suitable design that the length size of forklift is longer because of the suitable driving space


5.lower price compare the same machines


6.service is satisfied with our after-sales team and engineering team


Contact us

Laura Chen

Mobile/Whatsapp/Wechat: +86 18737330327

Email: laura @ oriemac.com




Parameter



Engine


































Type



Steyr WD615TI-3A


(water cooled, in-line,


direct injection and turbo charge)



Rated revolution



1850rpm



Rated power



120kw



Cylinder number-bore x stroke



6-126 x 130



Piston displacement



9.726



Rated fuel consumption



214g/kW.h



Max. Torque



764N.m






Undercarriage system






























Type



swing type of sprayed beam, suspended structure of wualizer bar



Carry rollers



2 each side



Track rollers



6 each side



Track type



Assembled, single-tooth, 38 each side



Width of track shoes



560mm



Pitch



216mm






Hydraulic system






















Max. Pressure



14MPa



Pump type



Gear pump



Discharge



262L/min



Working cylinder x number



120mm x2

















































Min. Ground clearance(mm)



405



Ground pressure(MPa)



0.078



Gradeability



30



Track gauge(mm)



2000



Dozing capacity(m3)



7.5



Blade height(mm)



1343



Blade width(mm)



3800



Max. Drop below ground(mm)



540



Operating weight



24020











Product Description





Bulldozer_SHANTUI_SD22_6.jpgBulldozer_SHANTUI_SD22_11.jpgBulldozer_SHANTUI_SD22-3_2.jpgBulldozer_SHANTUI_SD22F_6.jpgBulldozer_SHANTUI_SD22W_10.jpgBulldozer_SHANTUI_SD22W_12.jpgBulldozer_SHANTUI_SD22W_13.jpgBulldozer_SHANTUI_SD22W_15.jpg
