LY Gaohua is a professional design & manufacturer of cooling tower in China. Our main products are evaporative condenser, closed cooling tower, air cooled heat exchanger, "air cooling + evaporative cooling" composite closed cooling system, anti-white mist efficient cooling system, etc. The products are be used in power, chemical, metallurgy, petrochemical, coal chemical, air condition, food refrigeration industries and so on. We covers an area of 13,500m2 and hold certificates of ISO. Our products are popular in domestic and international markets.

Main Manufacture of Air cooled Heat Exchanger

 Air Cooled Heat Exchanger Description

An air-cooled heat exchanger, or called air cooler, is an industrial heat exchanger that uses Ambient air as cooling medium, where the fan forces air cross the Finned pipes to cool the high-temperature processing medium within the pipes. The air cooler is mainly composed of three basic parts: tube bundle, fan and structure, and auxiliary parts like louver and platform handrails. It uses natural air as cooling medium saving precious water, reducing the discharge of industrial waste water and protecting the natural environment.

Air Cooled Heat Exchanger Structure

Air Cooled Heat Exchanger Assemble

Air Cooled Heat Exchanger Type

1. Forced-draft Horizontal Air Cooled Heat Exchanger

2. Induced-draft Horizontal Air Cooled Heat Exchanger

3. Sloped-top Air Cooled Heat Exchanger

Air cooled Heat Exchanger Parts



Air Cooled Heat Exchanger Parameter

No.	Tube Bundle Type	Heat Exchanger Tube Qty.	Pressure MPa	Number of tube rows	Base tube area,m2	Fin area,m2	Net Weight,KG		Water-filled weight KG
							L-Type Finned Tube	DR-Type Finned Tube
1	GP12×3-4-172-1.6S-23.4/L(DR)-la	182	1.6	4	172	4025	7524	8529	810
2	GP12×3-4-172-2.5S-23.4/L(DR)-la		2.5				7563	8568
3	GP12×3-4-172-4.0S-23.4/L(DR)-la		4				7589	8594
4	GP12×3-4-172-1.6S-23.4/L(DR)-la	273	1.6	6	258	6037	10408	11915	1218
5	GP12×3-4-172-2.5S-23.4/L(DR)-la		2.5				10609	12116
6	GP12×3-4-172-4.0S-23.4/L(DR)-la		4				10939	12445
7	GP12×3-4-172-1.6S-23.4/L(DR)-la	364	1.6	8	344	8049	13591	15600	1625
8	GP12×3-4-172-2.5S-23.4/L(DR)-la		2.5				13590	15599
9	GP12×3-4-172-4.0S-23.4/L(DR)-la		4				13590	15599



Air Cooled Heat Exchanger Header Type

1. Pipe header

2. Semi-circular bonnet header

3. Cover plate header- for very dirty flows

4. Plug headers-generally the most used







Air cooled Heat Exchanger Tube Bundle

Air Cooled Heat Exchanger Fin Type

Advantages of Air Cooled Heat Exchanger

1. High Heat Transfer Coefficient:

2. Large Temperature Difference Correction Coefficient:

3. The Small Footprint:

Delivery of Air Cooled Heat Exchanger

Certificates of Air Cooled Heat Exchanger



Application of Air Cooled Heat Exchanger

Q: What's the types of air cooled heat exchanger ?

A: We have induced draft air cooled heat exchanger, forced draft air cooled heat exchanger and slopped top air cooled heat exchanger.



Q: Are you a trader or manufacturer?

A: We are a manufacturer of air cooled heat exchanger , especially in all kinds of air cooling, water cooling, evaporate cooling equipement.


Q: What is the delivery time of air cooled heat exchanger?
A: For air cooled heat exchanger, it will be finished within 75 days once receipt the pre-payment;
