DELIXI дуговые сварочные аппараты ZX7-315DD (MMA-315DD) одиночная панель 8 конденсаторов многоплатные кнопки MMA мини сварочный
- Категория: Other Arc Welders >>>
- Поставщик: Hangzhou,Delixi,Imp,&,Exp,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.92 $* | 0.52 $* |
| Aug-20-2025 | 0.64 $* | 0.37 $* |
| Jul-20-2025 | 0.14 $* | 0.22 $* |
| Jun-20-2025 | 0.63 $* | 0.39 $* |
| May-20-2025 | 0.24 $* | 0.47 $* |
| Apr-20-2025 | 0.12 $* | 0.10 $* |
| Mar-20-2025 | 0.68 $* | 0.78 $* |
| Feb-20-2025 | 0.43 $* | 0.58 $* |
| Jan-20-2025 | 0.70 $* | 0.20 $* |
Характеристики
Product Description
1.Features of ZX7-315D (MMA-315D) Single board ordinary 8 capacitors Multi-board buttons MMA mini welder machine
1. Advanced IGBT inverter technology, low consumption and high output
2. Digital control improves the reliability
3. All kinds of acid, alkalic electrodes are applicable
4. Wide range of power grid adaptation, 220V/380V switch automatically and precisely
5. High no load voltage, smooth and stable welding performance with minimal spatter
6. High speed fan brings effective dissipation and high duty cycle
7. Over-current, over-voltage and over-heat protection
2.Specifications of ZX7-315D (MMA-315D) Single board ordinary 8 capacitors Multi-board buttons MMA mini welder machine
| Product number | ZX7-250(Single Board) | ZX7-250(Digital) | ZX7-250(LCD) | ZX7-315-I(220/380V) | ZX7-400 Double Voltage |
| Input voltage | AC220V±15% | AC220V±15% | AC220V±15% | AC220V/380V±15% | 220V/380V |
| Frequency (HZ) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated input current (A) | 22.7 | 22.7 | 22.7 | 26.1 | 230 |
| Rated input capacity (KVA) | 4.8 | 4.8 | 4.8 | 5.45 | 11.3 |
| Rated output voltage (V) | 24.8 | 24.8 | 24.8 | 25.4 | |
| No-load voltage (V) | 62 | 62 | 62 | 70 | 75/65 |
| Current adjustment range (A) | 20-120 | 20-120 | 20-120 | 20-140 | 20-190 |
| Load duration (%) | 30 | 30 | 30 | 30 | 35 |
| effectiveness(%) | 85 | 85 | 85 | 85 | 85 |
| Power Factor | 0.7 | 0.7 | 0.7 | 0.7 | 0.7 |
| Product size (mm) | 125mm*210mm*300mm | 125mm*210mm*300mm | 125mm*210mm*300mm | 150mm*230mm*365mm | 220*390*300 |
| Packing size (mm) | 370mm*240mm*300mm | 370mm*240mm**300mm | 370mm*240mm**300mm | 460mm*270mm*350mm | 515x315x420 |
| Net weight (KG) | 2.77kg | 2.83kg | 2.77kg | 4.28kg | 7.3 |
| Gross weight (KG) | 3.33kg | 3.39kg | 3.33kg | 5.10kg | 8.4 |
3.Related Items of ZX7-315D (MMA-315D) Single board ordinary 8 capacitors Multi-board buttons MMA mini welder machine
