Камера 720P DSM ADAS для автомобиля 4G GPS WiFi Mobile
- Категория: Камера видеонаблюдения >>>
- Поставщик: Shenzhen,Citops,Systems,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 27.12 $* | 28.51 $* |
| Jul-16-2025 | 22.42 $* | 22.31 $* |
| Jun-16-2025 | 26.95 $* | 27.57 $* |
| May-16-2025 | 26.88 $* | 27.97 $* |
| Apr-16-2025 | 21.97 $* | 21.46 $* |
| Mar-16-2025 | 26.57 $* | 27.46 $* |
| Feb-16-2025 | 25.46 $* | 26.58 $* |
| Jan-16-2025 | 25.23 $* | 26.27 $* |
Характеристики
Product Description
Citops DSM prevents fatigue driving system using DSM camera to obtain images, by the movements of the visual tracking, target detection, recognition and other technology on the driver's driving behavior and physiological condition for testing, when the driver fatigue, distraction, make a phone call, smoking and other dangerous situations in the system setting time alarm to avoid accident.DSM system can effectively regulate the driving behavior of drivers and greatly reduce the incidence of traffi caccidents.
Key features
1. Fatigue driving warning
2. Abnormal sightwarnings
3. Call warning
4. Imagecover warning
5. Driver change warning6. Warning of camera failure
7. Supporte wide dynamic HDR response
8.360°adjustable Angle, high temperature resistance
2. Abnormal sightwarnings
3. Call warning
4. Imagecover warning
5. Driver change warning6. Warning of camera failure
7. Supporte wide dynamic HDR response
8.360°adjustable Angle, high temperature resistance
Specification
Item | Description | ||
Model | MX-DMSM-22 | ||
Parameter of Lens | Image sensor | 1080P CMOS IMAGE SENSOR | |
Optical format | 1/2.7 inch | ||
pixel | 1936H*1096V(1080P) | ||
Pixel size | 3.0*3.0um | ||
output format | 10-bit RGB Raw Data | ||
Image output video | Analog HD AHD signal | ||
Wide dynamic | 95DB | ||
lens structure | 4E | ||
aperture | 2.0 | ||
Lens resolution | 5 million pixels | ||
Angle | Horizontal H: 85° | ||
Vertical V: 45° | |||
IR filter | 940 IR | ||
Lamp beads | wavelength | 940nm | |
Number | 2 | ||
work environment | voltage | 12V | |
current | 230 mA±5 | ||
temperature | -20 ～ 70℃ | ||
Size | interface | 4PIN MicroTCA | |
Line length | 55cm | ||
weight | 175g | ||
Structure size | 77（L）*55（W）*89（H）mm | ||
