Диск Мощный сильный магнит неодимовый производитель для
- Категория: Rare Earth Magnets >>>
- Поставщик: Shenzhen,Aim,Magnet,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.74 $* | 0.26 $* |
| Aug-15-2025 | 0.62 $* | 0.69 $* |
| Jul-15-2025 | 0.29 $* | 0.49 $* |
| Jun-15-2025 | 0.33 $* | 0.32 $* |
| May-15-2025 | 0.7 $* | 0.89 $* |
| Apr-15-2025 | 0.27 $* | 0.83 $* |
| Mar-15-2025 | 0.61 $* | 0.61 $* |
| Feb-15-2025 | 0.12 $* | 0.6 $* |
| Jan-15-2025 | 0.76 $* | 0.50 $* |
Характеристики
N52 powerful super strong magnetic disc round neodymium magnets
1. Factory Price
2. Fast delivery (5~7 days)
3. Most strongest Customized Magnet
4. OEM Accept
5. AIM Magnet Company Found in 2006
Product Description
Disc powerful magnet strong magnet manufacturer for sale
Material | Sintered Neodymium-Iron-Boron ( NdFeB ) | |
Size | Custom | |
Shape | Disc/ Customized (block,disc,cylinder, bar, ring,countersunk, Segment,hook,cup, trapezoid, irregular shapes ,etc) | |
Performance | N38 / Customized (N33 N35 N38 N40 N42 N45 N48 N50 N52 …...) | |
Coating | Nickel/ Customised (Zn, Ni-Cu-Ni, Ni, Gold, Silver, Copper, Epoxy, Chrome, etc) | |
Size tolerance | ±0.05mm for diamater /thickness, ±0.1mm for width/ length | |
Magnetization | Thickness Magnetized, Axially Magnetized, Diametrally Magnetized, Multi-poles magnetized, Radial Magnetized. (Customzied specific requirements magnetized) | |
Max. Working Temperature | Grade | Max. Operating Temperatures |
N35-N52 | 80°C (176°F) | |
33M- 48M | 100°C (212°F) | |
33H-48H | 120°C (248°F) | |
30SH-45SH | 150°C (302°F) | |
30UH-40UH | 180°C (356°F) | |
28EH-38EH | 200°C (392°F) | |
28AH-35AH | 220°C (428°F) | |
Applications | Neodymium(NdFeB) Magnet are widely used in many fields, such as motors, sensors, microphones, wind turbines, wind generators, printer, switchboard, packing box , loudspeakers, magnetic separation, magnetic hooks, magnetic holder, magnetic chuck, ect. | |
Production Procedure
There is 9 step for the processing to assure the product quality Raw material incoming-warehouse inspection-cutting inspection-plating-magnetizing-full inspection(temperature test, SST test, magnetic flux meter)-package
Coating
The coating advantages of Strong magnetic rare earth small disc neodymium magnet N52
1. Our own electroplating factory ensures quality and delivery!
2. Thickness of coating is 4-6μm thicker than counterparts, coating adhesion is better, and corrosion resistance is stronger.
Surface | Coating | Thickness (Microns) | Color | Resistance |
Passivation |
| 0-1 | Silver Grey | Temporary Protection |
Nickel | Ni+Ni | 10-20 | Bright Silver | Excellent against Humidity |
Ni+Cu+Ni | ||||
Zinc | Zn | 8-20 | Bright Blue | Good Against Salt Spray |
C-Zn | Shinny Color | Excellent Against Salt Spray | ||
Tin | Ni+Cu+Sn | 15-20 | Silver | Superior Against Humidity |
Gold | Ni+Cu+Au | 10-20 | Gold | Superior Against Humidity |
Copper | Ni+Cu | 10-20 | Gold | Temporary Protection |
Epoxy | Epoxy | 15-25 | Black, Red, Grey | Excellent Against Humidity & Salt Spray |
Ni+Cu+Epoxy | ||||
Zn+Epoxy |
Certifications
Our customer
FAQ
1.Why are chosen us?
- We are a professional magnet manufacturer since 2006. Our plating factory is the benchmark in the Shenzhen NdFeB industry.
- No returned goods for five years in Europe market
- We provide magnets for a dozen of Fortune Global 500 enterprise
- In Europe market, 80% permanent magnets used for range hood are from AIM Magnet Co., Ltd. - Our company is the main supplier of American top wine box.
2. How to control the magnetic property?
Hight stander raw material
3. How to control the tolerance?
- 1. before ginding and cuting, we inspection the black product tolerance.
- 2. before and after coating, we will inspection the tolerance by AQL standard
4. How to guarantee the consistancy?
- 1. the sintering control will make sure the perfect consistancy.
- 2. we cut magnet by multi-wire sawing machine to guarantee the dimension consistancy.
5. How to control coating ?
- 1. we have a coatIng factory
- 2. after coating, first inspection by visual, and second is salt spray test, nickel 48-72 hours, zinc 24-48 hours
Welcom to contact
