•Excellent microprocessor control guarantees high reliability
•Boost and buck AVR for voltage stabilization
•Auto restart while AC is recovering
•Simulated sine wave
•Off-mode charging
•Cold start function
•Generator compatible
MODEL
GS3000
CAPACITY
3000va/1800W
INPUT
Voltage
220VAC/230VAC
Voltage Range
140-290 VAC/140-300 VAC
Frequency Range
≥40 Hz (auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)
220VAC/230VAC±10%
Frequency Range (Batt. Mode)
50Hz ±1Hz or 60Hz±1Hz
Transfer Time
Typical 4-8 ms, 13ms max
Waveform (AC. Mode)
Sine Wave
Waveform (Batt. Mode)
Simulated Sine Wave
BATTERY
Battery Type & Number
12v9ah*4
Maximum Charge Current
2.0A
Typical Recharge Time
6-8 hours up to 90% capacity
INDICATORS
LCD Display
ALARM
Battery Mode
Sounding every 10 seconds
Low Battery
Sounding every second
Overload
Sounding every 0.5 second
Fault
Continuously sounding
PROTECTION
Full Protection
Short circuit, Overload, overcharge and over discharge protection
PHYSICAL
Dimension
345 x 148 x 230
Net Weight (kgs)
20
ENVIRONMENT
Humidity
0-90 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 45dB(1m spacing)
MANAGEMENT
Communication Port
For cholce(USB&RJ45)
* Product specifications are subject to change without further notice
Our Services
1. OEM&ODM services acceptable.
2. Lots of cooperated agent for shipping by sea or by air.
3. 1year warrenty , if it is quality problem , we will provide the parts for free .
Little hint: 1.In the warranty period the machine has a problem, please contact the sales staff, we will be responsible for customer service. 2.Exceed the warranty period, improper operation and man-made damage, we will still give help and support,We will provide spare parts at a cost price. 3.According to the customer's needs, we can provide unconventional, but the cost may be slightly higher than the traditional machine.
Detailed Images
Exhibitions
FAQ
Q1: Why you should choose us?
---16 years UPS experiences
---Professional team for both oversea and domestic market
--UPS provider of SCO meeting 2015 and Shanghai-Kunming high-speed railway project
---Qualified product plus competitable prices
---Delivery in time
---Sincerely services
Q2: How is your after-sale service?
---We provide 12-24 months warranty since the delivery date and free maintenance /
replacement during warranty period.
Q3: What kind of certification you have?
---ISO9000, CE,ROHS,UL,and so on
Our products could pass different labor testing according to different countries’ requirements.
Q4: Delivery time:
---Standard products could be delivered within 15 days; customized products could be
