Компрессорные полугерметичные конденсаторные
- Категория: Другое теплообменное оборудование и оборудование для охлаждения >>>
- Поставщик: Yantai,Carsem,Refrigeration,Engineering,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.89 $* | 0.85 $* |
| Aug-19-2025 | 0.12 $* | 0.35 $* |
| Jul-19-2025 | 0.8 $* | 0.9 $* |
| Jun-19-2025 | 0.8 $* | 0.27 $* |
| May-19-2025 | 0.14 $* | 0.81 $* |
| Apr-19-2025 | 0.14 $* | 0.41 $* |
| Mar-19-2025 | 0.92 $* | 0.62 $* |
| Feb-19-2025 | 0.2 $* | 0.8 $* |
| Jan-19-2025 | 0.94 $* | 0.10 $* |
Характеристики
Products Description
1.With semi -hermetic compressor
2.With copper tube -Alu. Fin air cooled condenser or high efficient shell -tube water cooled condenser.
3.Air cooled cond ensing units with low noise and high efficient external rotor fan motor
4.With high quality China made or imported components
5.System with water -proof cable connection box for easy connection
6.A complete product range with wide temp. range available, can be used for keeping fresh, cold storage, ice making and cold water etc.
2.With copper tube -Alu. Fin air cooled condenser or high efficient shell -tube water cooled condenser.
3.Air cooled cond ensing units with low noise and high efficient external rotor fan motor
4.With high quality China made or imported components
5.System with water -proof cable connection box for easy connection
6.A complete product range with wide temp. range available, can be used for keeping fresh, cold storage, ice making and cold water etc.
Model code
HTB：Semi-hermetic condensing units Series code
F：Cooling Type ；F：Air-cooed S ：Water cooled.
03：Compressor . Nominal Watt(HP)
M：Applicable Temp. Code: H: High Temp. M ：Mid Temp. L ：Low Temp.
Y：Refrigerant Code: Y ：R404A/R507，None:R22
Model | HTBF02M | HTBF03M | HTBF03M | HTBF03M | HTBF04M | HTBF05M | |||||||||
Comp model | 2GES-2 | 2FES-3 | 2EES-3 | 2DES-3 | 2CES-4 | 4FES-5 | |||||||||
Temperature(°C) | -10°C~5°C | ||||||||||||||
Power supply | 380V/3Ph./50HZ | ||||||||||||||
Condenser | Fan Qty | 1 | 1 | 2 | 2 | 2 | 2 | ||||||||
Voltage（V） | 380 | 380 | 380 | 380 | 380 | 380 | |||||||||
Input(W) | 180X1 | 180X1 | 140X2 | 140X2 | 180X2 | 180X2 | |||||||||
Comp Cap. & Inpu | Te.-5°C | Cap(W) | 4270 | 5250 | 6570 | 7850 | 9660 | 10300 | |||||||
Input(KW) | 1.76 | 2.14 | 2.48 | 2.97 | 3.65 | 3.83 | |||||||||
Te.-10°C | Cap(W) | 3460 | 4250 | 5290 | 6330 | 7820 | 8270 | ||||||||
Input(KW) | 1.65 | 2.0 | 2.3 | 2.76 | 3.4 | 3.56 | |||||||||
Te.-15C | Cap(W) | 2780 | 3390 | 4190 | 5040 | 6250 | 6540 | ||||||||
Input(KW) | 1.53 | 1.86 | 2.11 | 2.53 | 3.12 | 3.25 | |||||||||
Pipe | Gas In(mm) | φ16 | φ16 | φ22 | φ22 | φ22 | φ22 | ||||||||
Liquid dia.(mm) | φ10 | φ10 | φ12 | φ12 | φ12 | φ12 | |||||||||
Overall Size | A(mm) | 620 | 620 | 960 | 960 | 1060 | 1300 | ||||||||
B(mm) | 650 | 650 | 680 | 680 | 680 | 750 | |||||||||
C(mm) | 560 | 560 | 460 | 510 | 720 | 670 | |||||||||
Installation size(AXB)(mm) | 580X350 | 580X350 | 920X380 | 920X380 | 1020X380 | 1260X410 | |||||||||
Related Products
Company Profile
Packaging & Shipping
FAQ
1. Q: Are you a factory or trading company?
A: We are a trading company .
2. Q: Purchasing concept
A: With the concept of fairness and friendliness, we customize the products need for our respected customers, and take the
products and services as our pur pose to deliver the products to you safely.
3. Q: What is your Minimum quantity?
A: Minimum Ordering Quantity≥1
4. Q: Delivery time
A: Delivery time is 30 days.
5. Q: Terms of payment
A: 50% of the total contract amount by t/t payment in advance, 50% of the total contract amount by t/t payment before shipment.
A: We are a trading company .
2. Q: Purchasing concept
A: With the concept of fairness and friendliness, we customize the products need for our respected customers, and take the
products and services as our pur pose to deliver the products to you safely.
3. Q: What is your Minimum quantity?
A: Minimum Ordering Quantity≥1
4. Q: Delivery time
A: Delivery time is 30 days.
5. Q: Terms of payment
A: 50% of the total contract amount by t/t payment in advance, 50% of the total contract amount by t/t payment before shipment.
