Горячая Распродажа хорошая цена без задержки VLAN 250m 2 SFP волоконный гигабитный стандарт Uplink 48 В PoE коммутатор 16

Technical parameter list

Product Name

18-Ports10/100/1000M PoE Switch

Model

HR901-AFG-162S

Connector Type

16*10/100/1000M PoE Ports + 2*Gigabit SFP Uplink Ports

Network Protocols

IEEE802.3

IEEE802.3u

IEEE802.3x

IEEE802.3ab

IEEE802.3z

PoE Parameters

PoE Standard: IEEE802.3af /IEEE802.3at

Max each port: 15.4W (IEEE 802.3af)

Max each port:30W (IEEE 802.3at)

PoE compatibility: IEEE 802.3af/at adaptive

PoE port output: DC48-55V

Power Pin : Power over spare pairs 1/2(+) , 3/6 (-)

Network Media

10BASE-T: Cat 5E UTP(≤250 meter)

100BASE-TX: Cat5 or more UTP (≤100 meter)

1000BASE-TX: Cat5 or more UTP (≤100 meter)

Optical

MultiMode Fiber: 850nm, 1310nm, Transmission Distance: 550m/2Km

Single-Mode Fiber: 1310nm, 1550nm, Transmission Distance: 20/40/60/80/100/120km

PerformanceSpecification

Bandwidth: 52Gbps

MAC: 8K

Packet Buffer Memory: 4M

Packet Forwarding Rate: 38.7Mpps

Power Supply

Power input: AC100-240V 50/60Hz,  Output: 52V5.76A,  Power Budget: 300W/400W

Working Environment

Operating Temperature: -20℃ ~ 50℃;

Storage Temperature: -40℃ ~ 80℃;

Operating Humidity: Max 90%, non-condensing

Storage Humidity: Max 95%, non-condensing

Working Height: Max to 10,000 feet (3,000 meters)

Storage Height: Max to 10,000 feet (3,000 meters)

Physical Parameter

Product Dimension (L*W*H): 410mm*185mm*50mm

Package Dimension (L*W*H): 468mm*274mm*81mm

N.W: 2.1KG

G.W: 2.7KG

Package Contents

1.Ethernet Switch:1 unit

2.User Guide:1 unit

3.Warranty Card:1 unit

4.Power Cord:1unit

5.1U Rack Mount: 1 pair

MTBF

100,000 hours

Certification

CE ,RoHS, FCC, CCC

Warranty

2 years
