Sentuo SL4-150 высокое качество V0 1kv электрической изоляции зажим для пирсинга подвесной кабеля
- Категория: Clamps >>>
- Поставщик: Zhejiang,Sentuo,Electric,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.57 $* | 0.88 $* |
| Aug-19-2025 | 0.18 $* | 0.52 $* |
| Jul-19-2025 | 0.43 $* | 0.51 $* |
| Jun-19-2025 | 0.99 $* | 0.73 $* |
| May-19-2025 | 0.83 $* | 0.2 $* |
| Apr-19-2025 | 0.20 $* | 0.69 $* |
| Mar-19-2025 | 0.59 $* | 0.44 $* |
| Feb-19-2025 | 0.55 $* | 0.67 $* |
| Jan-19-2025 | 0.12 $* | 0.51 $* |
Характеристики
GENERAL:
1. Piercing connector, simple installation, need not strip the cable coat;
2. Moment nut, piercing pressure is constant, keep good electric connection and make no damage to lead;
3. Self-seam frame,wet-proof,waterproof,and anti-corrosion,extend the using life of insulated lead and connector;
4. Adopted special connecting tablet, apply to joint of Cu(AI) and Cu(AI) or Cu and AI;
1. Piercing connector, simple installation, need not strip the cable coat;
2. Moment nut, piercing pressure is constant, keep good electric connection and make no damage to lead;
3. Self-seam frame,wet-proof,waterproof,and anti-corrosion,extend the using life of insulated lead and connector;
4. Adopted special connecting tablet, apply to joint of Cu(AI) and Cu(AI) or Cu and AI;
7. Arc surface design , apply to connection with the same (different) diameter, wide connection scope (0.75mm2-400mm2/td);
5. Small electric connecting resistance, connecting resistance less than 2.5 times of the resistance of branch conductor with the same length . in accordance with the standard DL/T765.1-2001;6. Special insulated case body, resistance to illumination and environmental aging, the insulation strength can up to 12kV.
PRODUCT DETAIL:
FEATURES AND BENEFITS:
Insulated shell: Made of high-quality insulation and flame retardant material, the shell is hard and not easy to break, corrosion-resistant, aging-resistant, much more durable.
Torque nuts&bolts: Nut in hot dip galvanized steel, the bolts with 8.8grade or more higher.
Seal compound: 6KV/min underwater test qualified.
Piercing blades: Tin plated,copper/brass/aluminum available. Good electrical conductivity and effective oxidation prevention.
Cable end cap: Quality guarantee 36 month after assembly.
Insulated shell: Made of high-quality insulation and flame retardant material, the shell is hard and not easy to break, corrosion-resistant, aging-resistant, much more durable.
Torque nuts&bolts: Nut in hot dip galvanized steel, the bolts with 8.8grade or more higher.
Seal compound: 6KV/min underwater test qualified.
Piercing blades: Tin plated,copper/brass/aluminum available. Good electrical conductivity and effective oxidation prevention.
Cable end cap: Quality guarantee 36 month after assembly.
TECHNICAL DATA:
Model | SL4-150 |
Main Line (mm²) | 35-150 |
Tap Line (mm²） | 35-150 |
Norminal Current (A) | 316 |
Size (mm) | 50*61*100 |
Weight (g) | 280 |
Piercing Depth (mm) | 3-4 |
Bolt (pcs) | 1 |
