Ультратонкая 15 6 дюймовая Безбумажная система видеоконференции скрытая ТВ-раскладка выдвижной ЖК-подъемник моторизированный компьютер ЖК-монитор
- Категория: >>>
- Поставщик: Guangzhou,Baolun,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.75 $* | 0.93 $* |
| Aug-18-2025 | 0.33 $* | 0.15 $* |
| Jul-18-2025 | 0.90 $* | 0.13 $* |
| Jun-18-2025 | 0.9 $* | 0.31 $* |
| May-18-2025 | 0.40 $* | 0.72 $* |
| Apr-18-2025 | 0.11 $* | 0.51 $* |
| Mar-18-2025 | 0.96 $* | 0.5 $* |
| Feb-18-2025 | 0.0 $* | 0.32 $* |
| Jan-18-2025 | 0.43 $* | 0.10 $* |
Характеристики
Paperless LCD monitor Lift system for conference room church
Products Description
The product adopts intelligent control technology, taking intelligent terminal as application concept, adopting original guide rail design. One key operation can automatically complete starting, LCD screen up, elevation and other actions, beautiful desktop, space-saving as the purpose, easy to use. With anti-theft, anti-dust, beautify desktop and other function. It can be widely used in conference, office hotel, teaching studio and other occasion, to meet the customer systems development diversity, and office automation environment demand. It is one ideal assistant of your office and teaching.
Features
* With ultra-thin HD touch screen and lifter integrated design, no exposed cable, no connection backboard, no exposed screws, ensure a nice overall appearance of touch display screen.
* Built in an elevating microphone, microphone up and down with automatic straightening function, when MIC bending, it will be automatically straightening when machine close, won’t be damaged.
* Equipment use all-aluminum structure, high-quality aluminum with CNC carved processing, display frame and chassis are made of aluminum alloy, to make equipment refined, lightweight, beautiful.
* Equipment surface treatment is anodized, bright color.
* Equipment panel thickness of only 3mm, width of only 70mm, small footprint.
* Adopt imported steel wire, cooperated with high precision guide rail and linear bearing, AC geared motor as driving force,
reduce noise to minimum.
* 15.6-inch ultra-thin LCD touch screen display, resolution up to 1920*1080P, clear and bright display, adjustable backlight
design, to prevent fatigue caused by too bright or too dark.
* Support HDMI and VGA two channel signal input, when there is only one signal input, the screen will automatically recognize this signal, when these two signal input at the same time, can be manually switched from panel key, when no signal input, the screen will automatically enter into power saving mode.
* The device can be centrally controlled through central control software, can be controlled by the host computer, one key can make all device in the room go up or down.
* Built-in loop-through output power outlet, can power supply to the terminal to reduce terminal power outlet wiring, make project site wiring more neat and beautiful.
* With USB port on the desktop panel, the user can read the file in the USB or upload files to the USB.
* Built in an elevating microphone, microphone up and down with automatic straightening function, when MIC bending, it will be automatically straightening when machine close, won’t be damaged.
* Equipment use all-aluminum structure, high-quality aluminum with CNC carved processing, display frame and chassis are made of aluminum alloy, to make equipment refined, lightweight, beautiful.
* Equipment surface treatment is anodized, bright color.
* Equipment panel thickness of only 3mm, width of only 70mm, small footprint.
* Adopt imported steel wire, cooperated with high precision guide rail and linear bearing, AC geared motor as driving force,
reduce noise to minimum.
* 15.6-inch ultra-thin LCD touch screen display, resolution up to 1920*1080P, clear and bright display, adjustable backlight
design, to prevent fatigue caused by too bright or too dark.
* Support HDMI and VGA two channel signal input, when there is only one signal input, the screen will automatically recognize this signal, when these two signal input at the same time, can be manually switched from panel key, when no signal input, the screen will automatically enter into power saving mode.
* The device can be centrally controlled through central control software, can be controlled by the host computer, one key can make all device in the room go up or down.
* Built-in loop-through output power outlet, can power supply to the terminal to reduce terminal power outlet wiring, make project site wiring more neat and beautiful.
* With USB port on the desktop panel, the user can read the file in the USB or upload files to the USB.
Specification
Model | TS-F156MT |
Touch Screen | Support |
Lifting time | 28S |
Elevation Angle | 0-30° |
Case Size | 540*60*647mm |
Panel Size | 555*70*3mm |
The lifting hole size | 388*21.5mm |
Desk cut-out size | 542*62mm |
Panel Chimtay Size | 556*71*3mm |
Working Environment | -20℃～50℃，relative humidity≤70% |
Screen Size | 15.6" |
Screen aspect ratio | 16：9 |
Resolution | 1920*1080 |
Video Port | 1 VGA、1 HDMI |
Control Port | 2 groups of 232/485 input and output ports to control microphone and screen lifting, support hand-by-hand connection, 1 USB port for switch on and off, 1 USB port for data transmission |
Microphone interface | Aviation 6 pin interface, support hand-by-hand connection |
Mic rod length | 415mm |
Backlight type | WLED,15K hour，with LED driver |
Contrast | 600：1 |
Brightness | 300cd/㎡ |
Viewing Angle | 45/45/20/40(Typ.) |
Screen Thickness | 9.7mm |
Power Suppply | AC 220V 50-60/HZ |
Power Consumption | 25W |
Weight | 12Kg |
Company Profile
About ITC
Guangzhou Baolun Electronic Co.,Ltd (ITC) was founded in 1993,with more than 500 professional engineers for different systems in R&D center and more than 3.000 staffs in total. We are professional manufacturer for audiovisual (PA system, speaker, amplifiers,
LED screen, Conference system and etc.) & lighting products. ITC has strict quality control, SMT production lines and imported raw materials from international brands, products comes with CE,RoHs,EN54,ISO,CCC certificates, meet Europe standard. Our products are exported to all over the world with good reputation. ITC successful cases exceed 1,000,000 all over the world.
LED screen, Conference system and etc.) & lighting products. ITC has strict quality control, SMT production lines and imported raw materials from international brands, products comes with CE,RoHs,EN54,ISO,CCC certificates, meet Europe standard. Our products are exported to all over the world with good reputation. ITC successful cases exceed 1,000,000 all over the world.
Certifications
ITC Factory
ITC has 5 manufacturing centers,2 R&D centers and 1 logistics center.Cause of the strong R&D ability and production capabilities, we provide customers with reliable products with excellent quality and timely delivery.In addition,we can also provide the trade, OEM and ODM service.
Factory Overview
Our Cases&Exhibition
Product packaging
Recommend Products
FAQ
Q: Are you manufacturer or trade company？
A: We are manufacturer, which located in NO.1 building B Block Zhongcun Street Panyu District of Guangzhou, Guangdong, China.
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments，Banks，Churches， Highways，Airports，Parliaments，Education institutes，Hotel，Private corporate conference hall and so on.
Q: What project did you have done in overseas?
A: *EXPO 2016 Antalya in Turkey
*International Airport in Tabatinga, Brazil
*The 7th South China Sea International Conference in Vietnam
*The Subway Center of Chanakyapuri in New Delhi, India
*Department of Public Works and Highways in Philippines.
A: We are manufacturer, which located in NO.1 building B Block Zhongcun Street Panyu District of Guangzhou, Guangdong, China.
Q: Do you offer OEM&ODM service?
A: Yes, we do.
Q: What’s the quality standard of your products?
A: Our products has approved CCC, ISO9001, CE, RoHS certification.
Q: Which place will use ITC equipment?
A: Our products are widely used in International Conferences, Governments，Banks，Churches， Highways，Airports，Parliaments，Education institutes，Hotel，Private corporate conference hall and so on.
Q: What project did you have done in overseas?
A: *EXPO 2016 Antalya in Turkey
*International Airport in Tabatinga, Brazil
*The 7th South China Sea International Conference in Vietnam
*The Subway Center of Chanakyapuri in New Delhi, India
*Department of Public Works and Highways in Philippines.
