Характеристики


LNG Tank trailer or tanker Trailer (United States usage) or tanker (United Kingdom usage), is a Trailer designed to carry Liquefied natural gas (LNG) is natural gas (predominantly methane, CH4, with some mixture of ethane C2H6) that has been converted to liquid form for ease and safety of non-pressurized storage or transport.The natural gas is then condensed into a liquid at close to atmospheric pressure by cooling it to approximately −162 °C (−260 °F); maximum transport pressure is set at around 25 kPa (4 psi). Because of LNG achieves a higher reduction in volume than compressed natural gas (CNG) so that the (volumetric) energy density of LNG is 2.4 times greater than that of CNG (at 250 bar) or 60 percent that of diesel fuel. This makes LNG cost efficient in marine transport over long distances and populared as an clean energy in these years.





































































































































































































































































53000L LNG Energy Tank semi trailer with 3 axles for Liquid Natural Gas9533GDY
overall dimension of the vehicle(mm)Length13000
Width2500
Height (unload)3890
Overall dimension of outer shell(mm)Length12850
Dia Φ2500
Overall dimension ofInner vessel(mm)Length12750
Dia Φ2500
capacity(L)53000
GVW(kg)40000
vehicle total weight(kg)19000
rated payload(kg)21000
Wheel base(mm)6960+1320+1320
Tread(mm)Tread at front
Tread at rear1840/1840/1840
Front/Rear Overhang(mm)/1520
Approach/Departure angle(°)/17.2
Rated payload of Vehicle saddle16000
AxleBPW 12T*3
Axle Capacity kgs8000/8000/8000
Tyres12R22.5*12
Tank MaterialS30408+Q345R
Transport Material :LNG
Insulated Cover
SuspensionSpring Leaf
Leaf Spring/8/8/8
remark:

Tank facility
Design pressure0.7MPa
(see technical proposals)
MAWP0.92MPa
(see technical proposals)
Capacity
Code & MaterialStainless Steel 304/ Q345R
vacuum Degress of Interspace Pa≤1*10^-1 Absolute Pressure
Static Evaporation %/D≤0.21 (LN2)
Thermal Insulation typeHigh-Vacuum Multi-Layer Insulation
Filling & Discharge SystemControl methodMechanical
Liquid dischargeSingle liquid discharge systemSide of the trailer
Valve boxSingle valve boxesSide of the trailer
ValesBrand
Emergency Valve (Liquid Phase)Rego
Emergency Valve(Gas Phase)Rego
PRVRego
Vent ValveRego
Liquid AdaptorRego
Gas AdaptorRego
Liquid Adapter CapRego
Gas Adapter CapRego
Pressure GaugeRego
Angle ValveFisher
ThermometerWIKA
Liquid Level GaugeRego
Ball valves (Liquid Phase)Modentic valve
Ball valves (Gas Phase)Modentic valve
