220 В Вибрационный двигатель для машины
US $22.00-$45.00
Линейный двигатель с постоянным
- Категория: Vibration Motor >>>
- Поставщик: Zhuhai,Cordy,Electronics,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.78 $* | 0.92 $* |
| Aug-16-2025 | 0.94 $* | 0.35 $* |
| Jul-16-2025 | 0.89 $* | 0.37 $* |
| Jun-16-2025 | 0.19 $* | 0.35 $* |
| May-16-2025 | 0.85 $* | 0.30 $* |
| Apr-16-2025 | 0.55 $* | 0.97 $* |
| Mar-16-2025 | 0.66 $* | 0.53 $* |
| Feb-16-2025 | 0.76 $* | 0.35 $* |
| Jan-16-2025 | 0.32 $* | 0.57 $* |
Характеристики
Products Description
Continuous thrust | 40N |
Peak Thrust | 120N |
Continuous current | 0.8Arms |
Maximum current | 2.4Arms |
Resistance | 17.4ohm |
Inductance | 66.1MH |
Thrust constant | 52.5N/Arms |
Rated speed | 3.5m/s |
Maximum speed | 5.3m/s |
Magnet attraction | 315N |
Coil size | 127*44*45mm |
Magnet track quality | 2.6kg/m |
Model | Coil model | Maximum stroke (mm) | Total length (mm) | Length of sliding table (mm) | Stage height (mm) | Moving mass (kg) | Stage weight (kg) | Hard limit position (mm) |
CD140 | C1 | 350 | 590 | 130 | 91.5 | 1.6 | 10.2 | 120 |
450 | 690 | 11.5 | 120 | |||||
550 | 790 | 12.8 | 120 | |||||
700 | 940 | 14.8 | 120 | |||||
800 | 1040 | 16.1 | 120 | |||||
900 | 1140 | 17.4 | 120 | |||||
1000 | 1240 | 18.7 | 120 | |||||
1100 | 1340 | 20 | 120 | |||||
1210 | 1440 | 21.3 | 120 | |||||
1310 | 1550 | 22.8 | 120 | |||||
Advantages.
1. Nearly zero cogging force to enhance low-speed stability and setting of pisitioning.
2. Built-in aluminum mounting plate for excellent heat dissipation and lighter weight.
3. Fully covered by metal shielding for eliminating EMI to nearby encoder head.
4. Ironless linear motor could be replaced for smaller size and better heat disspation.
Iron core linear motor
1. core technical competencies:
Vertical Machining Technology for Design of Ultra-precision Platform Direct drive motor design and
Vertical Machining Technology for Design of Ultra-precision Platform Direct drive motor design and
manufacture application technology :(DDL,DDR,VCM) Toughness and Hardware Technology of Motor Drive
New sensor R & D technology.
New sensor R & D technology.
2.Mature solutions:
Micro crystal test (Probe Card), IC manufacturing (IC Tester) TFT/LCD equipment (4.5 generation ~8.5 generation gantry) LED equipment (Die bonder,wire bonder,Sorter) PCB equipment (heavy plate machine, laser steel plate cutting) and so on.
Micro crystal test (Probe Card), IC manufacturing (IC Tester) TFT/LCD equipment (4.5 generation ~8.5 generation gantry) LED equipment (Die bonder,wire bonder,Sorter) PCB equipment (heavy plate machine, laser steel plate cutting) and so on.
Characteristics
1. the low speed stability and positioning setting of near-zero vibration intensity to reduce the curve following error. The slot effect force below 1\\8240; peak thrust is comparable to the performance of iron-free motor.
2.The locking surface is high thermal conductive aluminum plate, good heat dissipation and high thrust, reducing weight.
3.all metal coating to avoid electromagnetic interference to the nearby optical reading head.
4. forced cooling kit, instead of large thrust coreless linear motor, has the advantage of smaller volume and better heat dissipation.
5.thrust range of standard series products 18 N-10080N; at the same time customized motor volume, thrust, reasoning speed characteristics.
6.Japanese military industry quality standard material and manufacture guarantee.
7.Dynamic stator in Taiwan automatic assembly line production, rigorous quality assurance.
Applications:
Semiconductor equipment, LCD/LED manufacturing equipment, Laser cutting & engraving machines, CNC machining center, Material handling equipment etc....
FAQs about linear motor
1.What is a linear motor?
Linear motors are electric induction motors that produce motion in a straight line rather than rotational motion. In a traditional electric motor, the rotor (rotating part) spins inside the stator (static part); in a linear motor, the stator is unwrapped and laid out flat and the "rotor" moves past it in a straight line. Linear motors often use superconducting magnets, which are cooled to low temperatures to reduce power consumption.
Linear motors are electric induction motors that produce motion in a straight line rather than rotational motion. In a traditional electric motor, the rotor (rotating part) spins inside the stator (static part); in a linear motor, the stator is unwrapped and laid out flat and the "rotor" moves past it in a straight line. Linear motors often use superconducting magnets, which are cooled to low temperatures to reduce power consumption.
2.What are the benefits of a linear motor?
Linear motors are also referred to as direct drive units, since the load is directly coupled to the motor. This eliminates the
need for elastic components such as gearboxes and couplings, which introduce backlash and error in the motion. And because they do not rely on mechanical drive components such as ball screws, belts, and rack and pinions, linear motors have a much higher accuracy and repeatability, with no velocity ripple.This lack of rotating or recirculating parts also makes them virtually maintenance-free and contributes to a lower total cost of ownership when compared to traditional drive mechanisms.
Linear motors are also referred to as direct drive units, since the load is directly coupled to the motor. This eliminates the
need for elastic components such as gearboxes and couplings, which introduce backlash and error in the motion. And because they do not rely on mechanical drive components such as ball screws, belts, and rack and pinions, linear motors have a much higher accuracy and repeatability, with no velocity ripple.This lack of rotating or recirculating parts also makes them virtually maintenance-free and contributes to a lower total cost of ownership when compared to traditional drive mechanisms.
3.What is an Iron Core motor?
An Iron Core motor is a linear motor which is designed and constructed with an iron core. In iron core linear motors, the windings are mounted in an iron lamination stack. The number and length of the windings determine how much force the motor can produce.Based on the magnetic attraction, between the iron of the primary and the permanent magnets of the secondary, plus the magnetic force created in the windings. These linear motors offer extremely high continuous force for their size, starting at 60N for the small TM, all the way up to 3000N for the water cooled TBW powerhouse. Peak forces are even higher, reaching up to 6000N. With high continuous forces and good heat dissipation, iron core linear motors are ideal for pressing, molding, and machining applications.
An Iron Core motor is a linear motor which is designed and constructed with an iron core. In iron core linear motors, the windings are mounted in an iron lamination stack. The number and length of the windings determine how much force the motor can produce.Based on the magnetic attraction, between the iron of the primary and the permanent magnets of the secondary, plus the magnetic force created in the windings. These linear motors offer extremely high continuous force for their size, starting at 60N for the small TM, all the way up to 3000N for the water cooled TBW powerhouse. Peak forces are even higher, reaching up to 6000N. With high continuous forces and good heat dissipation, iron core linear motors are ideal for pressing, molding, and machining applications.
4.What is done to reduce the cogging effect of Iron Core motors?
To reduce cogging in Iron Core linear motors, Tecnotion has taken two measures. First, the magnet plate is constructed with a skewed magnet arrangement that smooths out the movement of the iron core. Second, Tecnotion Iron Core motors use a proprietary coil laminate that is specifically designed to reduce cogging.
To reduce cogging in Iron Core linear motors, Tecnotion has taken two measures. First, the magnet plate is constructed with a skewed magnet arrangement that smooths out the movement of the iron core. Second, Tecnotion Iron Core motors use a proprietary coil laminate that is specifically designed to reduce cogging.
5.What is cogging?
The permanent magnets produce an attraction force to all magnetic materials. Cogging is an result of the iron core motor design. The iron core has “preferred” positions relative to the magnets, and the motor must vary its thrust force to overcome these positions. This results in a motion that is less smooth than that of an ironless linear motor, and can be compared to moving over an old-fashioned washboard.
The permanent magnets produce an attraction force to all magnetic materials. Cogging is an result of the iron core motor design. The iron core has “preferred” positions relative to the magnets, and the motor must vary its thrust force to overcome these positions. This results in a motion that is less smooth than that of an ironless linear motor, and can be compared to moving over an old-fashioned washboard.
