RS232 Business Drading PVC RFID Card Vending Machine HCT-F1-2000



General

HCT-F1 series card dispenser is a high-performance card issuing device which primarily dispenses paper tickets and PVC cards to users according to instructions from HOST. It is primarily applicable to self-service terminals such as parking lot management system, expressway toll gate, self-service charging system, self-service card vending terminal, etc.



Feature

1. Unique dispensing wheel design: is capable of issuing various embossing cards accurately.

2. Convenient and simple card adjustment design: is stable and accurate to dispense cards with various thicknesses.

3. Compact structure design: effectively saves space for the complete machine.

4. Rear card capture box: provides convenience for card management.

5. Simple collection channel design: satisfies user requirement for large collection amount.

6. Multiple sensors: are able to judge the card position and indicate the card status.

7. Scientific card transfer wheel design: automatically avoids dust accumulation which will lead to slippage.

8. Multiple levels of sensor circuit protection: prevents optical interference.

9. Supports multiple communications (max. 16 C/Ds).

10. Supports online upgrade program.



Specification

Power Supply	DC24V ± 5%,< 1.5A
Quiescent Current	200mA
Communication Method	RS232 Interface, with capture box (multiple communications supported, with default address 00)
Service Life	≥ 1,000,000 passes
Card Stacker Capacity	155 pcs (0.76mm standard card)
	120 pcs (0.76mm embossing card)
	300 pcs (0.4mm thickness)
Capture Box Capacity	25 pcs (0.76mm standard card)
Net Weight	Approx.1.6KG(excluding accessories and package)
C/D Dimension	236L x 100W x 200H mm
Operation Temperature/ Humidity	-10°C to 70°C, 0 to 90% RH without condensation
Storage Temperature/ Humidity	-25°C to 80°C, 0 to 90% RH without condensation
Cards Supported	86L x 55W mm(0.2~1.2mm thickness; factory standard: 0.8mm)
