Датчик давления емкости 4-20

Категория: Датчики давления >>>
Поставщик: Microcyber,Corporation

Цена:292,00 $ - 319,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	347.44 $*	364.51 $*
Aug-16-2025	345.58 $*	362.64 $*
Jul-16-2025	289.79 $*	303.25 $*
Jun-16-2025	339.17 $*	356.57 $*
May-16-2025	295.25 $*	310.74 $*
Apr-16-2025	333.9 $*	350.82 $*
Mar-16-2025	330.31 $*	347.2 $*
Feb-16-2025	327.94 $*	343.66 $*
Jan-16-2025	324.50 $*	340.99 $*

Характеристики

Products Description

NCS Series of Intelligent Transmitters are digital, intelligent, network-based, merged with advanced, reliable and stable sensor technology, to be designed as a new generation of Fieldbus Intelligent Transmitter.

NCS Series of Intelligent Transmitter have been designed with high precision and high reliability, high stability. The pressure, temperature, currents and other physical quantities are displayed on LCD module. Zero drift, range settings and many other functions, are realized by the magnetism bar operation. The interoperability between different systems and equipments are realized by the Equipment Description Document, which is coMpatible to a variety of device management software, and adapting to harsh electromagnetic environment. NCS Series of Intelligent Transmitter have been used in inflammable and explosive places according to Intrinsically Safety Design.

NCS-PT105 series of Intelligent Pressure Transmitters are well- designed with advanced, mature and reliable capacitance sensors, combined with advanced microprocessor technology and digital capacitance measurement technology. Internal microprocessor make it intelligent, high-precise, high reliable and zero-point stable. It is easy to debug in the field.

NCS-PT105 Series of Intelligent Pressure Transmitters, complied with HART Protocol, have been used to measure pressure, level, flow and other industrial parameters, which have been widely used in petroleum, chemical, metallurgy, electricity, cement, etc.

NCS-PT105Ⅱ series Smart Pressure Transmitter with advanced, mature, reliable 3151 capacitance sensors has been designed meticulously by combining advanced microprocessor technology and digital capacitance measurement technology. The powerful functions and high-speed computing capability of the microprocessor make it have excellent qualifications such as smart, high precision, high reliability, stable zero and so on. Its LCD can display many physical parameters (e.g. pressure, temperature, current and so on). It can realize the functions such as zero adjustment, range settings by key-press operation, and it is easy for field testing.

NCS-PT105Ⅱ series Smart Pressure Transmitter supports HART, FF, and PA protocol and can measure pressure, differential pressure, liquid level, flow, and other industrial parameters. It can be widely used in the petroleum, chemicals, electricity, and metallurgical industries, etc..

According to the type of measurable pressure:

Model	Pressure type
NCS-PT105ⅡSG	Gauge Pressure Transmitter
NCS-PT105ⅡSA	Absolute Pressure Transmitter
NCS-PT105ⅡSD	Differential Pressure Transmitter
NCS-PT105ⅡSH	Differential Pressure Transmitter For High Static Pressure

As a transitional communication protocol in fuildbus, HART protocol achieves digital transmission on the existing analog transmission lines, and is coMpatible with existing analog signal control system. Either FF H1or PROFIBUS PA is a new generation of digital communication protocol, used in field connection, and linking field devices. International Standard IEC61158-2 is used in physical layer. Therefore, either FF H1or PROFIBUS PA is fieldbus actually.

As following, Smart Transmitter with HART protocol is named as HART Smart Transmitter; Smart Transmitter with FF H1 protocol is named as FF Smart Transmitter; Smart Transmitter with PROFIBUS PA protocol is named as PA Smart Transmitter, All of these (Transmitters with the three types of fieldbus protocol) are named as Smart Pressure Transmitters or Smart Transmitters. In addition, HART Smart Transmitter has passed explosion-proof certification from National Supervision and Inspection Center for Explosion Protection and Safety of Instrumentation (NEPSI).

Features
