Источник питания переменного тока 16 В 100 А 20 в 125 25 80 40 50 2000

PART 1. PRODUCT FEATURE

PART 2. 2000W SPECIFICATIONS

Brand

WEMAXPOWER

Model definition

WMX-ASD XXX YYY

XXX---Output Voltage ;YYY---Output Current

Model (WMX-ASD)

16125

20100

2580

4050

5040

8025

10020

12516

Input Voltage

Option

1 Phase: AC120V±10%,50Hz/60Hz;
1 Phase: AC220V±10%,50Hz/60Hz;(Standard)
3 Phase: AC208V AC380V / AC400V ±10%,50Hz/60Hz;
The price of 1 phase 120vac / 3 phase 380Vac Input is different.

Output Voltage (Vdc)

16V

20V

25V

40V

50V

80V

100V

125V

Output Current (Amp)

125A

100A

80A

50A

40A

25A

20A

16A

Output Voltage / Current adjustable

Output voltage adjustable range : 0~Max Voltage
Output Current adjustable range: 10% of max current ~ Max Current
If need 0~Max current , please contact with factory confirm

Output Power

1500W

Load Regulation

≤0.5%+30mV

Ripple

≤0.5% + 10mVrms

Power supply stability

≤0.3%+10mV

Voltage | Current Display Accuracy

Precision of 4 digit table : ±1%+1 word (10%-100% rating)

Voltage | Current value display Format

Display format: 0.000 ~ 9999V; 0.00 ~ 99.99V; 0.0 ~ 999.9A;

Output Voltage Overshoot

Build in O.V.P Protection with a rate of + 5%

Operation Temperature| Humidity

Operation Temperature : (0~40)℃; Operation Humidity : 10% ~ 85% RH

Storage Temperature | Humidity

Storage Temperature : (-20~70)℃; Storage Humidity :10% ~ 90% RH

Over-Temperature Protection

(75~85) C.

Heat Dissipation Mode/ Cooling mode

Forced air cooling

Efficiency

≥86%

Start-up Output voltage setting time

≤3S

Protection

lower voltage, over voltage, over current, short circuit, overheating Protection

Noted : if need addition Reverse Connection & Polarity reversal protection should be contact factory customized

Insulation Strength

Input output: AC1500V, 10mA, 1 minutes;

Input - machine shell: AC1500V, 10mA, 1 minutes;

Output - shell: AC1500V, 10mA, 1 minutes

Insulation Resistance

Input-Output ≥20MΩ;

Input-Output ≥20MΩ;

Input-Output ≥20MΩ.

MTTF

≥50000h

Dimension /Net Weight

350*150*160mm; NW: 7.0kg

Analog Remote Control Function (Option)

Remote Control Function (Option)

0-5Vdc /0-10Vdc analog signal control output voltage & current

0-5Vdc /0-10Vdc analog signal to read-back output voltage & current

0-5Vdc /0-10Vdc analog Switch signal to control output ON/OFF

4-20mA analog signal control output voltage & current

RS232/RS485 Communication port control by computer

Customized Service

Output Voltage/Current

1~20000V can customized,Stabilizer value. 0% to 100% adjustable

1~25000A can customized,Constant current value. 0% to 100% adjustable

Option, Free combination of voltage and current according on user request
