ZOOMLION грузовой кран 25 тонн Грузовые Краны ZTC250V431

ZOOMLION грузовой кран 25 тонн Грузовые Краны ZTC250V431

Категория: Автокраны >>>
Поставщик: Cruking,Engineering,Equipment,(Xiamen),Co.,Ltd.

Цена:81 700,00 $ - 82 100,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	97223.89 $*	102084.26 $*
Aug-18-2025	96406.68 $*	101226.99 $*
Jul-18-2025	80883.52 $*	84927.20 $*
Jun-18-2025	94772.83 $*	99511.58 $*
May-18-2025	82517.17 $*	86643.3 $*
Apr-18-2025	93138.43 $*	97795.41 $*
Mar-18-2025	92321.16 $*	96937.19 $*
Feb-18-2025	91504.40 $*	96079.17 $*
Jan-18-2025	90687.86 $*	95221.38 $*

Характеристики

ZOOMLION Mobile Crane 25ton Truck Crane

ZTC250R531 truck cranes

ZTC250V431 truck cranes

Contact Way

Products Description

Strong performance Boom
* The industry's longest five-section 42m "U" main boom, integrated lifting performance leading industry same tonnage products.
Precise and smooth operation
* The operation action is customized with a professional slow function, the minimum stable speed of rotation is 0.1°/s, and the minimum stable speed of lifting is 2.5m/min, which satisfies the precise lifting operation.
SUV Travelling in the crane
* The low-speed and high-torque transmission system for construction machinery has strong power and the maximum speed is 90km/h; Meet the requirements of the G class, the driving pass is better.
Energy-saving and environmental protection
* Intelligent multi-power mode energy-saving system, the average fuel consumption of the operation is 3.0L/h, and the overall fuel economy is 20%.

Intelligent communication
* The telematics platform moves the in-vehicle information to the remote and realizes all-round information management through the mobile app.

Product Paramenters

		Unit	ZTC250H431	ZTC250V431	ZTC250V531	ZTC250R531
Working performance	Max. rated lifting capacity	kg	25000	25000	25000	25000
		Max. load moment of basic boom	kN.m	960	960	960	960
		Max. load moment of main boom(fully extended)	kN.m	672	600	598	598
		Max. lifting height of main boom	m	35.4	35.4	40.2	40.2
		Max. lifting height of jib	m	43	43	47.8	47.8
Working speeds	Max. hoist rope speed(Main winch)	m/min	120	135	135	135
		Max. hoist rope speed(Auxiliary winch)	m/min	120	135	135	135
		Boom Crukinging up time	s	25	25	25	25
		Boom telescoping out time	s	64	25	82	82
		Slewing speed	r/min	2.7	0 -2.7	0 – 2.7	0 -2.7
Driving parameters	Max. driving speed	km/h	90	90	85	85
		Max. gradeability	%	42	42	42	42
		Min turning diameter	m	≤20	≤20	≤20	≤20
		Min. ground clearance	mm	260	250	250	250
		Oil consumption per hundred kilometers	L	28	28	28	28
Mass	Deadweight in driving condition	kg	29600	27800	30600	30600
		Complete vehicle kerb mass	kg	29470	27670	30470	30470
		Front axle load	kg	6300	6500	6500	6500
		Rear axle load	kg	23300	21300	24100	24100
Dimensions	Overall dimensions(L×W×H)	mm	13100×2500×3450	13100×2500×3450	12600×2500×3450	12600×2500×3450
		Longitudinal distance between outriggers	m	5.4	5.4	5.4	5.4
		Transversal distance between outriggers	m	Fully extended: 6.2m, Intermediately extended: 4.25m	Fully extended: 6.2m, Intermediately extended: 4.25m	Fully extended: 6.20m Intermediately extended: 4.25m	Fully extended: 6.2m, Intermediately extended: 4.25m,
		Tail slewing radius	mm	3265	3265	3265	3265
		Main boom length	m	10.7-35	10.7 - 35.0	10.2 - 40.0	10.2 - 40.0
		Boom angle	°	-82	-1 - 80	-81	-1 - 80
		jib length	m	8	8	8	8
		Offset	°	0/15/30	0,15,30	0/15/30	5,17,30

Details Images
