TK-7Y регулятор солнечного нагрева воды под давлением
US $10.00-$30.00
Резервуар для горячего солнечного
- Категория: Солнечные водонагреватели >>>
- Поставщик: Jiangsu,Sunpower,Solar,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 19.54 $* | 19.21 $* |
| Jul-17-2025 | 15.14 $* | 15.58 $* |
| Jun-17-2025 | 19.19 $* | 19.98 $* |
| May-17-2025 | 19.80 $* | 19.76 $* |
| Apr-17-2025 | 15.26 $* | 15.91 $* |
| Mar-17-2025 | 18.13 $* | 18.68 $* |
| Feb-17-2025 | 18.30 $* | 18.42 $* |
| Jan-17-2025 | 18.71 $* | 18.19 $* |
Характеристики
SPC Parameter
AL frame solar water heater tanks SPC series
Model | Capacity (Net) L | Tank dia mm | Vacuum tube size and No. | Weight Kg | 20ft/ 40HQ sets |
SP-420-47/1500-15-C | 84 | 420 | 47/1500/15pcs | 58 | 73/170 |
SP-420-47/1500-18-C | 100 | 420 | 47/1500/18pcs | 62 | 60/139 |
SP-420-47/1500-24-C | 133 | 420 | 47/1500/24pcs | 76 | 47/109 |
SP-420-47/1500-27-C | 150 | 420 | 47/1500/30pcs | 78 | 42/93 |
SP-420-47/1500-30-C | 166 | 420 | 47/1500/36pcs | 86 | 39/90 |
SP-470-47/1500-13-C | 100 | 470 | 47/1500/13pcs | 60 | 66/150 |
SP-470-47/1500-18-C | 139 | 470 | 47/1500/18pcs | 68 | 56/130 |
SP-470-47/1500-20-C | 150 | 470 | 47/1500/20pcs | 72 | 48/111 |
SP-470-47/1500-24-C | 179 | 470 | 47/1500/24pcs | 79 | 41/95 |
SP-470-47/1500-30-C | 226 | 470 | 47/1500/30pcs | 91 | 34/79 |
SP-470-58/1800-12-C | 100 | 470 | 58/1800/12pcs | 63 | 44/100 |
SP-470-58/1800-15-C | 122 | 470 | 58/1800/15pcs | 78 | 42/97 |
SP-470-58/1800-18-C | 150 | 470 | 58/1800/18pcs | 84 | 41/95 |
SP-470-58/1800-20-C | 165 | 470 | 58/1800/20pcs | 90 | 37/86 |
SP-470-58/1800-24-C | 200 | 470 | 58/1800/24pcs | 110 | 32/74 |
SP-470-58/1800-30-C | 250 | 470 | 58/1800/30pcs | 130 | 25/58 |
SP-470-58/1800-36-C | 300 | 470 | 58/1800/36pcs | 150 | 23/50 |
We can produce Direct plug Integrated Lower Pressure System Water Heaters ,Integrated Pressurized Solar Water Heaters,Heat Pipe Solar Collectors,Flat Plate Solar Collector,U Pipe Solar Collector,Storage Water Tank,Solar Project,Solar Water Heater Accessory ..for you.
Production Description | |
Type | SP(Integrated Low Pressure System) |
Outer Tank Material | White color steel or Food grade SUS304 2B stainless steel plate |
Outer Tank Diameter | 460mm,470mm, 500mm |
Inner Tank Material | Food grade SUS304 2B stainless steel plate or 316L stainless steel |
Inner Tank Diameter | 360mm, 380mm |
Tube Material | High quality borosilicate glass |
Vacuum Tube Size(mm) | 58/1800 (diameter/length) |
Tube Number | 9/10/12/15/18/20/24/30/32/36/40 |
Frames (Stand Parts) | Galvanized plate, Stainless steel or Aluminum alloy |
Insulation Layer | High quality polyurethane foam made by advanced high pressure foam machine |
Insulation Thickness | 50mm,(outer tank 460mm),55mm(outer tank 470mm), 60mm(outer tank 500mm) |
Hail Resistance | 25mm |
Operation Pressure | 0.05Mpa |
Standard Qualified | CE, CCC,Solar Keymark EN12976, SABS |
Tell me your specific needs. I will recommend the most suitable products for you, arrange the fastest production time for you and provide you with the best quality service.
SPA Parameter
Heat pipe solar collector specification(SPA-C,SPA,SPB) | ||||
| SPA-C | SPA | SPB | |
Sloping roof photo |
|
|
| |
Flat roof photo | ||||
Manifold casing material | Stainless steel 304 | Aluminum alloy | Aluminum alloy | |
Manifold size | 130*140 mm | 100*130 or 100*135 mm
| 150*170 mm | |
Aluminum fin | single long pcs | single long pcs | single long pcs | |
Vacuum tube | Three targets | Three targets | Three targets | |
Tube cover | Screw type | Screw type | Screw type | |
Reflector | excluded | excluded | excluded | |
Frame material | Stainless steel | Aluminum alloy | Thickened and dilated Aluminum alloy material | |
Collector Performance Data(SP) | 0.714 | |||
Optimal flow rate | 0.1L/min/tube-0.026G/min/tube | |||
Max. Test pressure | 9bar | |||
Outer copper tube diameter | 22mm | |||
Inner copper tube diameter | 20mm | |||
Insulation | 140kg/m3 mineral wood | |||
Max. Test pressure | 9bar | |||
Optimal installation angle | 30-70°vertical, O° horizontal | |||
Tell me your specific needs. I will recommend the most suitable products for you, arrange the fastest production time for you and provide you with the best quality service.
