Rubflex clutch WCB2 water cooled tensionser 124WCB2 pressure plate

Rubflex clutch WCB2 water cooled tensionser 124WCB2 pressure plate

Категория: Industrial Brake >>>
Поставщик: Henan,Dalin,Rubber,And,Telecommunications,Apparatus,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.48 $*	0.28 $*
Aug-18-2025	0.38 $*	0.24 $*
Jul-18-2025	0.50 $*	0.11 $*
Jun-18-2025	0.91 $*	0.71 $*
May-18-2025	0.37 $*	0.91 $*
Apr-18-2025	0.12 $*	0.1 $*
Mar-18-2025	0.49 $*	0.83 $*
Feb-18-2025	0.91 $*	0.22 $*
Jan-18-2025	0.91 $*	0.13 $*

Характеристики

Product Description

The WCB2 water-cooled tensioner is designed for constant tension applications. It is exceptionally well suited for high inertia stopping and rapid heat dissipation. The design of the WCB2 tensioner permits mid-shaft or end-shaft mounting. The rugged construction ensures long, trouble free service.

How it works

Air pressure is applied through the ports in the cylinder causing the piston an pressure plate assembly to move towards the mounting flange, compressing the release springs. As the applied pressure increases, the friction discs are clamped between the pressure plate and the mounting flange, stopping or controlling the shaft the discs are mounted on. Modulation of air pressure then controls applied torque of the tensioner. Multiple disc brakes utilize reaction plates between discs. The release springs assist in disengegement and retraction of the piston, pressure plate, and reaction plates, if applicable. High heat dissipation is accomplished by passing water through a special cavity behind the copper alloy wear plates.

Specification

8WCB2	14WCB2
18WCB2	24WCB2
36WCB2	48WCB2

Typical application

Forestry

Logging equipment

Anchor handling

Towing winches

Mooring winch systems

Petroleum drilling equipment

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

Company Profile

Henan Dalin Rubber and Telecommunications Apparatus Co.,ltd specializes in designing and manufactuering of pneumatic clutches and brakes since 1975, our main products are CB CLUTCH, VC CLUTCH, DISC PNEUMATIC CLUTCH , also spare parts such as clutch air tube, clutch FSA, clutch male drum and female drum, friction disc, pressure plate, drive plate, water jacket, drive plate assembly, Seal, cyliner, pressure plate, wear plate etc. All of them can be 100% interchanged with international brand

Certifications

Details Information

Parts	124WCB2	224WCB2	324WCB2	424WCB2
Description	Part No.	Part No.	Part No.	Part No.
Mounting Flange Sub Assy	513348-01	513348-01	513348-01	513348-01
Mounting Flange	513337	513337	513337	513337
Wear Plate	508459	508459	508459	508459
Stud	000245*0069	000245*0071	000245*0081	000245*0082
Friction Disc	508725	508725	508725	508725
Friction Disc Core	510745	510745	510745	510745
Clamp Tube	306542-05	306542-20	306542-23	306542-24
Pressure Platesub Assy	513348-03	513348-03	513348-03	513348-03
Pressure Plate	513345	513345	513345	513345
Flat Washer	000153*0641	000153*0641	000153*0641	000153*0641
Locknut	000110*0073	000110*0073	000110*0073	000110*0073
Cylinder	513264	513264	513264	513264
Polypak Seal	000402*0023	000402*0023	000402*0023	000402*0023
Polypak Seal	000402*0024	000402*0024	000402*0024	000402*0024
Gear (not included with assembly)	411672	410970	412433	413195
Wear Spacer		308396	308396	308396
Reaction Plate Sub Assy		513348-02	513348-02	513348-02
Reaction Plate		513343	513343	513343
Piston	513317	513317	513317	513317
Release Spring	416751-02	416751-02	416751-02	416751-02
Inner Support Ring	413107	413107	413107	413107
Outer Support Ring	413108	413108	413108	413108
Flat Head Screw	000294*407	000294*407	000294*407	000294*407
Pipe Plug	000077*0021	000077*0021	000077*0021	000077*0021
