Высокое качество горнодобывающей промышленности керамической фильтр-пресс машина

Высокое качество горнодобывающей промышленности керамической фильтр-пресс машина

Категория: Filter Press Equipment >>>
Поставщик: Woking,Environmental,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.44 $*	0.37 $*
Aug-16-2025	0.12 $*	0.2 $*
Jul-16-2025	0.52 $*	0.29 $*
Jun-16-2025	0.73 $*	0.81 $*
May-16-2025	0.96 $*	0.19 $*
Apr-16-2025	0.14 $*	0.24 $*
Mar-16-2025	0.67 $*	0.57 $*
Feb-16-2025	0.7 $*	0.52 $*
Jan-16-2025	0.58 $*	0.95 $*

Характеристики

Product Description

Applications

Filter press is suitable for almost all types of slurry, such as: ceramics industry, stone industry, glass industry,
mining & minerals industry, coal washing, sand washing, pull&paper industry, food industry, chemical & pharmacy industry,
electroplating industry, textile& dyeing, leather industry, municipal slurry etc.

Feature

lower residual moisture, High capture rate, low energy requirement, Reliable, automatic operation, Solid and robust design for demanding operating conditions, Long service life, High operating availability, Free access to plate pack, Special design for aggressive media, Customer-oriented process solution thanks to modular design

Technical Parameters

Filter area(㎡)	Plate size(mm)	Chanbers No.	Totd volume(L)	Working pressure(Mpa)	External Dimensions(LWH)(mm)	Machine weight(KG)
120	1250X1250	46	1800	≤0.6	4990X1620X2030	7900
140	1250X1250	54	2100	≤0.6	5470X1620X2030	8400
160	1250X1250	62	2400	≤0.6	5950X1620X2030	8900
180	1250X1250	70	2700	≤0.6	6430X1620X2030	9400
*200	1250X1250	76	3000	≤0.6	6790X2130X2100	9900
*250	1250X1250	96	3750	≤0.6	8030X1620X2030	11200

Optional facility

Specification

item	value
Applicable Industries
After Warranty Service	Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location	United States, Viet Nam, Thailand, Malaysia
Showroom Location	United States, Viet Nam, Thailand, Malaysia
Video outgoing-inspection	Provided
Machinery Test Report	Provided
Warranty of core components	1 Year
Core Components	PLC
Condition	New
Automatic Grade	Automatic
Place of Origin	China
Brand Name	WOKING
Voltage
Dimension(LWH)
Warranty	1 Year
After-sales Service Provided	Online support
