144 полуэлементов солнечной энергии 500 Вт монокристаллический PV модуль Солнечная
- Категория: Солнечные батареи для сварочного шлема >>>
- Поставщик: Shenzhen,Topsky,Energy,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.10 $* | 0.5 $* |
| Aug-17-2025 | 0.83 $* | 0.40 $* |
| Jul-17-2025 | 0.63 $* | 0.76 $* |
| Jun-17-2025 | 0.47 $* | 0.80 $* |
| May-17-2025 | 0.52 $* | 0.98 $* |
| Apr-17-2025 | 0.46 $* | 0.35 $* |
| Mar-17-2025 | 0.78 $* | 0.67 $* |
| Feb-17-2025 | 0.4 $* | 0.13 $* |
| Jan-17-2025 | 0.22 $* | 0.99 $* |
Характеристики
210mm cells mono silicon 480w 490w panels solar trina panels
Products Description
Main features of 500w or above solar panel:
*Global Tier 1 bankable brand, with independently certified state-of-the-art automated manufacturing
*Low LCOE, reduced BOS cost, short payback time, lower degradation.
*Large area cells based on 182mm/210mm solar wafers, up to 21% module efficiency with high density interconnect technology.
*Multi bus bar technology for better light trapping effect, lower series resistance and improved current collection.
*Minimized micro-cracks with innovative non-destructive cutting technology.
*Certified to withstand severe environmental conditions
1.Anti-reflective & anti-soiling surface minimise power loss from dirt and dust
2.Severe salt mist, ammonia & blown sand resistance, for seaside,farm and desert environments
3.Excellent mechanical load 2400Pa & snow load 5400Pa resistance
*Global Tier 1 bankable brand, with independently certified state-of-the-art automated manufacturing
*Low LCOE, reduced BOS cost, short payback time, lower degradation.
*Large area cells based on 182mm/210mm solar wafers, up to 21% module efficiency with high density interconnect technology.
*Multi bus bar technology for better light trapping effect, lower series resistance and improved current collection.
*Minimized micro-cracks with innovative non-destructive cutting technology.
*Certified to withstand severe environmental conditions
1.Anti-reflective & anti-soiling surface minimise power loss from dirt and dust
2.Severe salt mist, ammonia & blown sand resistance, for seaside,farm and desert environments
3.Excellent mechanical load 2400Pa & snow load 5400Pa resistance
Electrical Characteristic of 500w solar cells panel | ||||||||||
Rated Maximum Power(Pmax) [W] | 480 | 485 | 490 | 495 | 500 | |||||
Open Circuit Voltage(Voc) [V] | 50.8 | 51.1 | 51.3 | 51.5 | 51.7 | |||||
Maximum Power Voltage(Vmp) [V] | 42.0 | 42.2 | 42.4 | 42.6 | 42.8 | |||||
Short Circuit Current(Isc) [A] | 11.99 | 12.07 | 12.14 | 12.21 | 12.28 | |||||
Maximum Power Current(Imp) [A] | 11.42 | 11.49 | 11.56 | 11.63 | 11.69 | |||||
Module Efficiency [%] | 20.1 | 20.3 | 20.5 | 20.7 | 20.9 | |||||
Power Tolerance | 0~+5W | |||||||||
Temperature Coefficient of Isc(α_Isc) | +0.04%/℃ | |||||||||
Temperature Coefficient of Voc(β_Voc) | -0.26%/℃ | |||||||||
Temperature Coefficient of Pmax(γ_Pmp) | -0.36%/℃ | |||||||||
STC | Irradiance 1000W/m², cell temperature 25℃, AM1.5G | |||||||||
Packing information
No.of solar cells | Solar panel Thickness of frame | PCS/Pallet | 20GP(PCS) | 40HC(PCS) |
full 60cells | 35mm | 30 | 360 | 840 |
half-cell 120 cells | 35mm | 30 | 360 | 780 |
full 72cells | 40mm | 27 | 270 | 720 |
half-cell 144cells | 40mm | 27 | 270 | 660 |
FAQ
Q: What kind of certification do you have?
A: Power from 3W to 500W solar panels with TUV,IEC61215/IEC61730,CEC,CE,UL,ETL,PID,ISO.MCS,etc.
Q: What is the warranty of poly solar panels and mono solar panel?
A: 10 years warranty on material and workmanship, 25 years power warranty (90% power output in 10 years,80% in 25 years)
Q: Can you quote me the best price?
A: We need more information about your demands, such as the power/material/Qty/etc, then We can suggest the suitable type and
quote the best price for you.
Q: Can I just order some samples of small quantity?
A: Sample order in small quantity is acceptable.
A: Power from 3W to 500W solar panels with TUV,IEC61215/IEC61730,CEC,CE,UL,ETL,PID,ISO.MCS,etc.
Q: What is the warranty of poly solar panels and mono solar panel?
A: 10 years warranty on material and workmanship, 25 years power warranty (90% power output in 10 years,80% in 25 years)
Q: Can you quote me the best price?
A: We need more information about your demands, such as the power/material/Qty/etc, then We can suggest the suitable type and
quote the best price for you.
Q: Can I just order some samples of small quantity?
A: Sample order in small quantity is acceptable.
Why Choose Us
Professional Service
1. Our sales representative and engineer work together to answer your questions and offer solution for free
2. We choose the best product for you to make sure it worth its real value
3. We design the best solution with good perfomance for you,manwhile save every cent of your money
2. We choose the best product for you to make sure it worth its real value
3. We design the best solution with good perfomance for you,manwhile save every cent of your money
Reliable Supplier.
1. We provide 10 years Warranty for the product, 10 years warranty for 90% power production ,25 years warranty for 80% power production.
2.We are authorized distributor of Suntech&Csun brand panels---one of the most famous tier-1 brand manufacturer in the world. We welcome your any inquiry.
