Jucolor новейший A0 струйный большой Печатный i3200-U1 печатающая головка на кожаном стекло акрил древесина плитка УФ
- Категория: Печатное устройство >>>
- Поставщик: Shanghai,Colorjet,Industry,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.99 $* | 0.89 $* |
| Aug-17-2025 | 0.67 $* | 0.11 $* |
| Jul-17-2025 | 0.47 $* | 0.13 $* |
| Jun-17-2025 | 0.35 $* | 0.67 $* |
| May-17-2025 | 0.44 $* | 0.52 $* |
| Apr-17-2025 | 0.98 $* | 0.50 $* |
| Mar-17-2025 | 0.5 $* | 0.82 $* |
| Feb-17-2025 | 0.70 $* | 0.98 $* |
| Jan-17-2025 | 0.51 $* | 0.59 $* |
Характеристики
Machine Advantage
Newest CJ-R1610UV A0 UV flatbed printer with 3 print heads for large format 164*115*19cm printing size ,it can printing CMYK white and varnish at the same time on rotary and flat material for all Ad.
Printing Samples
Product Description
Model | CJ-R1610UV Large A0 UV Printer |
Print Head | 3 pcs EP SON I3200-U1/TX800/XP600 Print Heads |
Max Printing | 164*115 CM /64.5*45 Inches |
Printing Height | 19cm/7.5 inches print thickness |
Inks Color | CMYK+White +Varnish uv led curing inks |
Printing Speed | 15 m2/h (720*720dpi) |
12 m2/h (720*1440dpi) | |
8 m2/h (1440*1440dpi) | |
Print Resolution | 720dpi, 1440dpi, 2160dpi, 2880 dpi, 3200dpi 4800 dpi |
Printing Materials | Pen, Phone Case, Glass, Plastic, Board, Leather, Rubber, Lighter, Metal, Wood, Porcelain, PVC, ABS, Acrylic, Aluminum, Ceramic Tile, Marble, Granite, Paper etc. |
Printing Software | Maintop/ Photoprint |
Picture Mode | PSD/ TIFF/ BMP/ EPS/ JPG |
Computer System | Windows 7/Window 8/Window 10 |
Date Interface | USB3.0 High Speed Interface Transfer System |
Power | 50-60Hz, 1000-1500W,110 V/ 220 V |
Working Environment | Temperature 25-30℃; Humidity 40%~60% |
Machine Size | 255*168*131 CM |
Package Size | 270*185*157.5 CM |
Machine Weight | Net.550KG/Gross.680KG |
Vacuum Adsorption Platform
164*115 cm printing size of vacuum adsorption table with margin rule mark which can allow to print on the flexible media also,more productively.
Double Fixed Ball Screw
CJ A0 UV printer uses HI-WIN 13.5 cm double straight square rail on X axis which drive the carriage move more high precision.Long working hours, anti-defamation, anti-oxidation, corrosion resistance.
Printing Height
The height of the suitable material can be automatically adjusted by the software, and the printing can be 18 cm high
Ink Alarm System 500ML/Bottle
8-color ink cartridge design, makes the print effect is more realistic .The white ink circulation system work constantly keep white ink from sediment and last the lifespan of print head.
Automatic Cleaning & Protection Heads
Automatic print head wipe and keep wet system. Automatic flushing when power on and keep wet when off. Just for prevent print head clog during idle and after printing.
Printer head bracket
CJ A0 uv printer is 3 heads design,support 3 PCS EP XP600/I3200-U1 heads ,one pass printing for all color CMYK white varnish
HI-WIN Guide Rail On Y-axis
CJ A0 Plus with 2 pieces HI-WIN straight square & strong screw rail on Y-axis which makes printing smoother and machine lifespan longer
Metal Support On Z-axis
Strong/heavy duty frame made by cast aluminum alloy, ensuring the smooth running of the carriage and work longer time
Air Suction Pump
1610 uv printer is bigger printer, we use air suction pump for this printer's suction platfrom, so can sucked the printed medias strongly with mute system, it runs more silently
CJ-R1610UV Igus Belt
From Germany belt high precision and anti-friction.Well protect lines and water pipes, no deformation for decades using
Customer Feedback
Company Profie
Product packaging
Model | CJ-R1610UV A0 UV Flatebed Printer | |
Shipping Size | 270*185*157.5 CM | |
Gross Weight | 580 KG | |
Packing | International Plywood Case | |
Shipping Methods | Express,Sea,Air,Land Shipping | |
Shipping Within 3-5 Days | ||
