Протектор Напряжения DC солнечный протектор напряжение

Протектор Напряжения DC солнечный протектор напряжение

Категория: Other Electrical Equipment >>>
Поставщик: Wenzhou,Xinchi,International,Trade,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.91 $*	0.67 $*
Aug-17-2025	0.10 $*	0.66 $*
Jul-17-2025	0.71 $*	0.89 $*
Jun-17-2025	0.66 $*	0.34 $*
May-17-2025	0.62 $*	0.32 $*
Apr-17-2025	0.43 $*	0.14 $*
Mar-17-2025	0.73 $*	0.71 $*
Feb-17-2025	0.37 $*	0.53 $*
Jan-17-2025	0.57 $*	0.48 $*

Характеристики

Why Choose Us

Product Details

SUP2H-PV Series Surge Protector			SUP2H1-PV	SUP2H1-PV	SUP2-PV
UCPV (V DC)			1000V	1200V	1500V
Max System Discharge Current (8/20 μs) [Imax]			40kA	40kA	40kA
Voltage Protection Level [UP]			≤4.0kV	≤4.5kV	≤4.5kV
Voltage Protection Level at 5kA [UP]			≤3.6kV	≤4.0kV	≤5.0kV
Integrated Fuse Breaking Capacity/Interrupting Rating			40kA/1000Vdc	40kA/1200Vdc	40kA/1500Vdc
Technology			Short-Circuit Interruption (SCI) Overcurrent Protection
Operating Temperature Range [TU]			-40°C to +80°C
Nominal Discharge Current (8/20 μs) [(DC+/DC-) --> PE] [n]			20kA
Response Time [tA]			<25ns
Operating State/Fault Indication			Green (good)/Red (replace)
Conductor Ratings and Cross-Sectional Area	Min	60/75°C 1.5mm2/14AWG Solid/Flexible
		Max	60/75°C 35mm/2AWG Stranded/25mm2/4AWG Flexible
Mounting			35mm DIN Rail per EN 60715
Enclosure Material			UL 94V0 Thermoplastic
Degree of Protection			IP20
Capacity			3 Modules, DIN 43880
Standards Information			IEC 61643-31 Type 2, IEC 61643-1 Class II
Product Warranty			Five Years**

Packing and Shipping

Company Information

FAQ

Q:When I can receive quotation and detail information after send the enquiry?
A: Reply will be sent in 24hours.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q:Can I get a sample for test before place order?
A:Of course!

Q:How's the delivery?Because I really need them is urgently?A: Samples cost 5-7 days. Bulk order cost 12-15 days.
A: Samples cost 5-7 days. Bulk order cost 12-15 days.

Q: What's your shipment method?
A: We ship by Express, by air, by sea, by train.

Q: If i want to release order, what's the payment method you accept ?
A: We accept T/T, Paypal, Western union, L/C, Trade Assurance.
