Характеристики
Product Description
SPECIFICATIONS FOR SHOE UPPER KNITTING MACHINE | ||||||
GAUGE | 14G | |||||
KNITTING SYSTEM | Three system single carriage | |||||
KNITTING WIDTH | 36INCH 52INCH 60INCH 66INCH 72INCH | |||||
KNITTING SPEED | MAX.1.2m/sec | |||||
KNITTING FUNCTION | Tranfer,Tuck,Miss,Jacquard,Intarsia,Hide or Apparent Shaping | |||||
STITCH DENSITY | Stitch system controlled by stepping motor ,32 section stitch selectable ,adjustable scope supported by subdivision technology :0-650. | |||||
RACKING | Controlled by AC servo motor,racking within 2 inches and with fine adjusting function. | |||||
Drive System | Synchronous belt drive,AC servo system. | |||||
Needle Selection | Controlled by computer,electric magnet needle choose system with high efficiency. | |||||
Yarn Carrier | 2x8YARN CARRIERS ON EACH SIDE OF 4 GUIDE RAILS,SHIFTABLE ON ANY NEEDLE POSITION | |||||
Take Down Roller | Programmed instruction controlled by stepping motor,32 section levels selection adjustable area:0-100. | |||||
Protection System | The machine will automatically alarm if yarn breaking,float yarn,rewind,end of knitting,fail of racking,needle breakage and error programming occur ect.Automatic reset needle detector is convenient and reliable. | |||||
Control System | 1.Adopt lcd screen,input device:usb,system memory 2G,a great amount of design files can be stored. 2.Monitoring menu,each knid of operating parameter,can be shown,and they can be adjusted at any time when the machine is running. 3.Design system is visual and easy to understand and upgrad. 4.Multi language version,there are chinese,english etc. | |||||
Power | 220v,single-phase,have memorizing function at the power-off moment. | |||||
Details Images
Positive yarn provider .
Positive yarn providing,successfully reduce yarn resistance ,increase knitting efficiency.
Carriage.
The speed can be adjusted swiftly and the position is precise ,which avoids the useless movement and greatly elevates the productivity of the machine.
Needle bed.
Divided structure ,steel sheet made from import high quality steel precisely punched and fine polished to reduce the resistance with needles and increase the longvity.
Side yarn bracket.
The side yarn bracket has safely alarms,which has sensors that are immune to the interference from the environment,capable of keeping their sensitivity from the beginning to the end.
