SINOTRUK 6x6 полный привод грузового

 Representative vehicle models

  ZZ1311M3861V

 CAB

Model

L2000

Type

High cab

 Engine

Model

WD615.47

Rated power kW/rpm

371hp/336hp

Maximum torque Nm/rpm

1160/1100-1600

Displacement L

9.726

 Clutch

Φ 420 Coil spring clutch

 Transmission

China National heavy duty truck HW Series

 Front axle

HF7

 Driving axle

HW1279

 Steering system

ZF8098 .

 Electrical system

24V : 12V/165Ah ×2

 Tire

11.00-20 OR 12.00-20

 Fuel tank capacity L

350

 Curb weight (whole vehicle / Chassis) kg

12270/10520

 Total mass kg

31000

 Rated contained mass kg

18600

 Vehicle dimensions (l x w x h) mm

10970x2490x3935

 Chassis dimensions (l x w x h) mm

10970x2490x3935

 Wheel base mm

1800+3800+1350

 Front suspension / Rear suspension (vehicle / Chassis) mm

1320/2700

 Track width (front / After) mm

2041/1850

 Minimum ground clearance mm

247

 Approach angle / Angle of departure (whole              Vehicle / Chassis) °

20.5/11

 Maximum speed km/h

90

 Maximum grade ability %

24

 Minimum turning diameter m

18.8

 Box dimensions (l x w x h) mm

8600x2280x800

 Container volume m³

15.6

 Notes

Optional WD615.62
