60W 100W 120W 150W 200W Складная солнечная панель для RV 12V техники батарея jackery rockpal солнечный генератор
- Категория: Солнечные панели >>>
- Поставщик: Shenzhen,Glory,Industries,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 146.60 $* | 149.10 $* |
| Jul-20-2025 | 118.83 $* | 120.89 $* |
| Jun-20-2025 | 144.46 $* | 147.24 $* |
| May-20-2025 | 143.17 $* | 146.8 $* |
| Apr-20-2025 | 114.13 $* | 116.15 $* |
| Mar-20-2025 | 140.89 $* | 143.96 $* |
| Feb-20-2025 | 139.24 $* | 142.8 $* |
| Jan-20-2025 | 138.58 $* | 141.66 $* |
Характеристики
PRODUCT INFORMATION
Specifications – SunPower series – 20W/fold | |||||
Item No. | GSF-80W | GSF-100WA | GSF-120W | GSF-200WA | |
Max power | 80W(4 folds) | 100W(5 folds) | 120W(6 folds) | 200W(10 folds) | |
Power tolerance | ±3% | ±3% | ±3% | ±3% | |
Cells brand | SunPower | SunPower | SunPower | SunPower | |
Cells efficiency(%) | 22.60% | 22.60% | 22.60% | 22.60% | |
Max voltage | 26.4V | 16.5V | 19.8V | 33.1V | |
Max current | 3.03A | 6.06A | 6.06A | 6.05A | |
Open circuit voltage(Voc) | 31.7V | 20V | 23.6V | 39.8V | |
Short-circuit current(Isc) | 3.52A | 7.03A | 7.03A | 7.01A | |
Unfolded size | 1140*400*5mm | 1420*400*5mm | 1700*400*5mm | 1560*820*5mm | |
Folded size | 400*300*18mm | 400*300*23mm | 400*300*27mm | 410*305*45mm | |
Weight | 1.4kgs | 2.2kgs | 2.6kgs | 4.5kgs | |
Operating Temperature(℃): | -40℃~+85℃ | ||||
Power temperature coefficient | -0.39 to -0.29 %/℃ | ||||
Voltage temperature coefficient | -0.29%/℃ | ||||
Current temperature coefficient | +0.05%/℃ | ||||
Nominal Operating Cell Temperature | 45 ± 2℃ | ||||
Measured at STC Condition: irradiance: 1000W /m2-AM1.5 Spectrum-Temperature: 25℃ | |||||
PRODUCT ADVANTAGE
RECOMMENDED PRODUCTS
PRODUCTION PROCESS
ABOUT US
WHY CHOOSE US
1. 17 Years Portable Solar Power Manufacture
GLORY SOLAR has 17 years manufacturing experience in portable solar power industry.
2.Most Products have Design Patents
Most of GLORY SOLAR 's products have design patents, and unique design can greatly reduce the competitiveness of the market.
3. ODM /OEM Design Service
GLORY SOLAR has powerful design team with 10 senior R&D staffs which could meet different customers need.
4. 24 Hours Customer Service
Our 10 profession sales can solve your problem timely.
5. 1-3 Years Warranty
We offer 1-3 years warranty for our solar panel and provide professional after-sales service.
6. More Than 32 Different Portable Solar Power Panel Kits for Your Reference
We supply foldable SunPower solar panel kits, foldable MONO solar panel kits, flexible SunPower solar panel, solar maintainer and customized solar panel.
7. Accept Alibaba Trade Assurance Order
We have joined Trade Assurance Service to protect your order, so as to ensure deliver on time and produce quality.
8. Free Sample on Stock
We make stock for our hot sales items, and we welcome to order sample to test and check quality. Low MOQ, 1pc for sample checking is available. Mixed samples are acceptable. Free sample is available for intentional cooperation.
